Iiyama LH6565UHSB-B1 164,0 cm (65") 16:9 2xHDMI+DP+2xUSB IPS retail (freight shipping)
|
1.099,32 EUR |
|
|
( 1.308,19 EUR incl. VAT ) ≈ £920.13 | ≈ $1,225.74 plus delivery charges: 235,00 € |
|
| Delivery time from supplier's stock (ca.) 3 workdaysinfo_outline | |
| In Stock: >10 pieces | |
| End-Of-Life: | 18. Sep 2026 |
|---|---|
| Datasheet: | file_download Download |
| Lieske Part No.: | 1214188 |
| Mfg Part No: | LH6565UHSB-B1 |
| UPC/EAN: | 4948570123582 |
| Weight: | 30 kg |
| Type: | LFD |
Product information for Iiyama LH6565UHSB-B1:
• Bild: 163,8 cm ( 64,5 inch )/163,9cm, 3840x2160, @60Hz, 16:9 • Kontrast: 1200:1 • Reaktion: 8ms • Helligkeit: 800 cd/m² • Anschlüsse: 2x HDMI, 1x DisplayPort, 1x RS-232c, 1x LAN, 1x MiniJack, 2x USB 2.0 • VESA: 400x400 • Maße: 1456,5x832,5x65mm
| Audio | |
| Number of built-in speakers | 2 |
| RMS rated power | 20 W |
| Built-in speaker(s) | |
| Computer system | |
| Processor manufacturer | ARM |
| Processor family | ARM Cortex |
| Processor architecture | ARM Cortex-A73 |
| Processor cores | 8 |
| Internal memory | 4 GB |
| On-board graphics card model | ARM Mali-G52 |
| Internal storage capacity | 32 GB |
| Operating system installed | Android 11 |
| Computer system | |
| Built-in processor | |
| Design | |
| Product design | Kiosk design |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| Panel mounting interface | 400 x 400 mm |
| Bezel width (bottom) | 1.49 cm |
| Bezel width (side) | 1.49 cm |
| Bezel width (top) | 1.49 cm |
| Bezel colour | Black |
| VESA mounting | |
| Display | |
| Panel type | IPS |
| Display diagonal | 163.8 cm (64.5") |
| Display technology | LED |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 800 cd/m² |
| HD type | 4K Ultra HD |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.372 x 0.372 mm |
| Active display area (W x H) | 803.52 x 680.72 mm |
| Display diagonal (metric) | 163.9 cm |
| Horizontal scan range | 28 - 160 kHz |
| Native refresh rate | 60 Hz |
| Haze rate | 1% |
| RGB colour space | NTSC |
| Touchscreen | |
| Network | |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Ethernet LAN | |
| Wi-Fi | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | -20 - 60% |
| Storage temperature (T-T) | -20 - 60 °C |
| Other features | |
| Power supply type | Internal |
| Quick start guide | |
| Packaging content | |
| Cables included | AC, HDMI, RS-232 |
| Remote control included | |
| Packaging data | |
| Package width | 1345 mm |
| Package depth | 162 mm |
| Package height | 1016 mm |
| Package weight | 28.7 kg |
| Performance | |
| Purpose | Commercial |
| Number of OSD languages | 8 |
| On Screen Display (OSD) languages | Traditional Chinese, Czech, Danish, German, English, Spanish, Finnish, French, Italian, Japanese, Norwegian, Dutch, Polish, Russian, Swedish |
| Operating hours (hours/days) | 24/7 |
| HDCP version | 2.2 |
| Mean time between failures (MTBF) | 50000 h |
| On Screen Display (OSD) | |
| HDCP | |
| Ports & interfaces | |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2 |
| USB ports quantity | 2 |
| USB version | 2.0 |
| Ethernet LAN (RJ-45) ports | 1 |
| Audio (L/R) in | 1 |
| USB port | |
| RS-232 interface | |
| RS-232C | |
| Power | |
| Power consumption (typical) | 104 W |
| Power consumption (standby) | 0.4 W |
| Power consumption (off) | 0.3 W |
| Energy efficiency class (SDR) | E |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 104 kWh |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Energy efficiency scale | A to G |
| Technical details | |
| Playback media | Y |
| User controls | picture (brightness, contrast, sharpness, black level, tint, colour, noise reduction, gamma selection, low blue light, colour temperature, colour control, picture reset), screen (zoom mode, custom zoom, screen reset), audio (balance, treble, bass, volume, audio out, maximum volume, minimum volume, mute, audio reset, audio out sync, speaker setting), configuration 1 (Android launcher, switch on state, panel saving, RS232-routing, boot on source, WOL, configuration 1 reset, factory reset), configu |
| Sustainability certificates | ErP |
| Compliance certificates | CE, REACH, RoHS, TÜV mark, UKCA, WEEE |
| Weight & dimensions | |
| Display width | 1456.5 mm |
| Display depth | 56 mm |
| Display height | 832.5 mm |
| Display weight | 20.7 kg |
| Width | 1456.5 mm |
| Depth | 56 mm |
| Height | 832.5 mm |
| Weight | 20.7 kg |
Please note...
We have listed this article as 'end-of-life', which means that it will only be sold until it is completely sold out ! Please mind that we cannot guarantee you, you will receive the article, although it may be betokened as available. You can find the date from when the article was marked end-of-life to the top.
Questions & answers
What is the delivery time of Iiyama LH6565UHSB-B1 164,0 cm (65") 16:9 2xHDMI+DP+2xUSB IPS retail (freight shipping)?
The article Iiyama LH6565UHSB-B1 164,0 cm (65") 16:9 2xHDMI+DP+2xUSB IPS retail (freight shipping) is currently in stock
According to our experience the article is ready for dispatch within 3 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Iiyama LH6565UHSB-B1 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Iiyama LH6565UHSB-B1 164,0 cm (65") 16:9 2xHDMI+DP+2xUSB IPS retail (freight shipping) always at the best possible price. We can give you a discount of 2% on Iiyama LH6565UHSB-B1 164,0 cm (65") 16:9 2xHDMI+DP+2xUSB IPS retail (freight shipping) if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
