Hager mounting machine 1-pole C32 MCS132, Quick Connect plug-in technology
|
40,47 EUR 42,17 EUR |
|||||||||||
|
( 48,16 EUR incl. VAT ) ≈ £34.24 | ≈ $45.25 plus delivery charges: 53,00 € |
|||||||||||
| Delivery time from supplier's stock (ca.) 2 workdaysinfo_outline | |||||||||||
| In Stock: >10 pieces | |||||||||||
| Lieske Part No.: | 805852 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | MCS132 | ||||||||||
| UPC/EAN: | 3250614315213 | ||||||||||
| Weight: | 0.1211 kg | ||||||||||
| Type: | MCS132 | ||||||||||
|
Graduated prices net
|
|||||||||||
Further Circuit breaker from HagerFurther products in category Circuit breaker
All products of Hager
Product information for Hager MCS132:
Circuit breaker switch QuickConnect rated capacity 6 kA - Standard: DIN VDE 64
Part
/ 8.92, EN 6 898/IEC 6898 (QC terminal: Appendix J) - limiting class 3 - Rated voltage 23/4 V ~ - possible accessory attachment - - With installation-friendly quick connect terminal on the outlet + access individual withdrawal from the phase rail network possible - shock protection to DIN VDE
Part 6
- Phase busbars, connectors, end caps from October 2 4 characteristic C, DIN VDE 64
Part
/ 8.92 Type:
pin current: 32 A Type: MCS
32
ST.
Part
/ 8.92, EN 6 898/IEC 6898 (QC terminal: Appendix J) - limiting class 3 - Rated voltage 23/4 V ~ - possible accessory attachment - - With installation-friendly quick connect terminal on the outlet + access individual withdrawal from the phase rail network possible - shock protection to DIN VDE
Part 6
- Phase busbars, connectors, end caps from October 2 4 characteristic C, DIN VDE 64
Part
/ 8.92 Type:
pin current: 32 A Type: MCS
32
ST.
| General | |
| Release characteristic | C |
| Number of poles (total) | 1 |
| Number of protected poles | 1 |
| Rated current | 32 A |
| Rated voltage | 400 |
| Rated insulation voltage Ui | 500 V |
| Rated impulse withstand voltage Uimp | 4 kV |
| Rated short-circuit breaking capacity Icn EN 60898 at 230 V | 6 kA |
| Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V | 10 kA |
| Voltage type | AC |
| Frequency | 60 |
| Current limiting class | 3 |
| Over voltage category | 3 |
| Pollution degree | 2 |
| Width in number of modular spacings | 1 |
| Built-in depth | 70 mm |
| Degree of protection (IP) | IP20 |
| Ambient temperature during operating | 70 |
| Connectable conductor cross section multi-wired | 25 |
| Connectable conductor cross section solid-core | 35 |
| Power loss | 4.40 W |
| Concurrently switching N-neutral | |
| Additional equipment possible | |
| Explosion-proof | |
| Flush-mounted installation | |
Questions & answers
What is the delivery time of Hager mounting machine 1-pole C32 MCS132, Quick Connect plug-in technology?
The article Hager mounting machine 1-pole C32 MCS132, Quick Connect plug-in technology is currently in stock
According to our experience the article is ready for dispatch within 2 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Hager MCS132 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Hager mounting machine 1-pole C32 MCS132, Quick Connect plug-in technology always at the best possible price. We can give you a discount of 2% on Hager mounting machine 1-pole C32 MCS132, Quick Connect plug-in technology if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 10 pieces of Hager mounting machine 1-pole C32 MCS132, Quick Connect plug-in technology we can offer you a price of 36,83 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
