Dold 0060495 SP9277.39CT AC220-240V 2.5-25A under-overcurrent relay

Your rating:
Average rating
product review for Dold 0060495 SP9277.39CT AC220-240V 2.5-25A under-overcurrent relay
( 4.6 / 5 ) 11 ratings
Dold 0060495
This image may differ from the desired article.
548,56 EUR
( 652,79 EUR incl. VAT )
≈ £459.14  |  ≈ $602.87
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x Dold 0060495 SP9277.39CT AC220-240V 2.5-25A under-overcurrent relay
Datasheet:file_download Download
Lieske Part No.:1313057
Mfg Part No: 0060495
UPC/EAN: 4030641604950
Weight:0.302 kg
Type:SP9277.39CT AC220-240V 2,5-25A
Graduated prices net
From piecesPrice per pieces
3544,45 EUR
6540,33 EUR
9536,22 EUR
12532,10 EUR

Product information for Dold 0060495:

The Dold SP9277.39CT is a 3-phase current relay for monitoring currents in alternating and rotating current networks. It is designed for detecting overcurrent and undercurrent and is specifically conceived for use in industrial and railway applications. The device operates on the zero-current principle, whereby the output relay is not activated in the event of a fault, ensuring a safe and defined response during disturbances. The auxiliary voltage is AC 220–240 V, and the relay features 2 x 2 changeover contacts as output contacts, which can be used for controlling auxiliary circuits or alarms.

Applications
This relay is suitable for continuous monitoring of electrical loads in industrial plants, such as in production lines, pump or ventilation systems. It can also be used in railway installations, where precise current monitoring is required for the safety and reliability of operational equipment. The 3-phase measurement enables simultaneous monitoring of all phases in a three-phase system, allowing detection of unbalanced loads or phase loss.

Functions and Equipment in Detail
The device includes an integrated current transformer, covering a measurement range of 2.5 to 25 A. Measurement is performed by passing the conductors through the transformer, ensuring galvanic isolation between the measurement circuit and the auxiliary circuit. The adjustable switching delay of 0.1 to 20 seconds allows adaptation to specific requirements, such as filtering out short-term current peaks. The hysteresis is fixed at approximately 4 %, ensuring stable switching behavior without oscillations at threshold values. The separate threshold setting for overcurrent and undercurrent enables differentiated monitoring, with the switching point adjustable between 0.1 and 1 times the rated current.

Technology Explained Simply
The relay operates on a zero-current principle, where the output relays are energized during normal operation and de-energized when a threshold value (overcurrent or undercurrent) is reached. This is particularly advantageous in systems where a shutdown in the event of a fault must ensure that no unintended activity occurs. The LED indicators signal the operating status: a green LED indicates normal operation, a red LED for I max indicates overcurrent, and a red LED for I min indicates undercurrent. This visual feedback simplifies diagnosis and maintenance.

Compatibility and Accessories
The device is designed for mounting in enclosures and can be installed either on DIN rails or by screws. The width is 70 mm, making it suitable for standard enclosure installations. The galvanic isolation between the auxiliary circuit and the measurement circuit increases safety and prevents interference in the control circuit. The relay is part of the VARIMETER series from Dold and can be combined with other devices in this series, particularly models that also support 3-phase measurement and similar output contacts.

Mounting and Installation
Mounting is performed in an enclosure, with connection terminals located at the top. Terminal designations are clearly defined: A1/A2 for auxiliary voltage, i1/k1, i2/k2, i3/k3 for measurement phases, and contacts 11–44 for output relays. The selection of the measurement range is done via jumpers on terminals Z1–Z4. Installation requires passing the conductors to be monitored through the integrated current transformer, ensuring correct phase assignment.

Operational Advantages
The SP9277.39CT provides reliable and precise current monitoring with clear signals via LED indicators. The adjustable time delay and separate threshold setting allow flexible adaptation to different applications. Galvanic isolation and the zero-current principle enhance safety and prevent false alarms. The device complies with the standard IEC/EN 60255-1, confirming adherence to international standards for measuring and protective devices.

Technical data
1- / 3-phase3
Enclosure designSwitch cabinet
Output contacts2 x 2 C/O contacts
Width70 mm
TypeSP 9277CT
Operate delayYes
Variant
Auxiliary voltageAC 220 - 240 V
Contact equipping2 x 2 changeover contacts
Measuring range2,5 - 25 A
Time delay0,1 - 20 s
Variant3-phase current relay with built in CT. De-energized on trip


Product data sheet
Datasheet for Dold 0060495, EAN: 4030641604950

Questions & answers

What is the delivery time of Dold 0060495 SP9277.39CT AC220-240V 2.5-25A under-overcurrent relay ?

The article Dold 0060495 SP9277.39CT AC220-240V 2.5-25A under-overcurrent relay is currently not in stock and must be ordered on a per-order basis.

According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Dold 0060495 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Dold 0060495 SP9277.39CT AC220-240V 2.5-25A under-overcurrent relay always at the best possible price. We can give you a discount of 2% on Dold 0060495 SP9277.39CT AC220-240V 2.5-25A under-overcurrent relay if you choose payment in advance on ordering.

In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 3 pieces of Dold 0060495 SP9277.39CT AC220-240V 2.5-25A under-overcurrent relay we can offer you a price of 544,45 EUR per piece. The more you buy, the cheaper the article will be.
