Dold 0050518 BF9250.01/001 UH=DC24V AC25A semiconductor contactor AC24-480V

Your rating:
Average rating
product review for Dold 0050518 BF9250.01/001 UH=DC24V AC25A semiconductor contactor AC24-480V
( 4.6 / 5 ) 7 ratings
Dold 0050518
This image may differ from the desired article.
224,05 EUR
( 266,62 EUR incl. VAT )
≈ £187.53  |  ≈ $246.23
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x Dold 0050518 BF9250.01/001 UH=DC24V AC25A semiconductor contactor AC24-480V
Datasheet:file_download Download
Lieske Part No.:633829
Mfg Part No: 0050518
UPC/EAN: 4030641505189
Weight:0.605 kg
Type:BF9250.01/001
Graduated prices net
From piecesPrice per pieces
5215,65 EUR
10207,25 EUR
15198,84 EUR
20190,44 EUR

Product information for Dold 0050518:

The Dold semiconductor contactor BF9250.01/001 is a 1-pole, zero-voltage switching contactor for use in industrial and technical installations. It is designed for frequent and noiseless switching of loads such as heaters, motors, valves, and lighting. The device is operated by an auxiliary voltage of AC/DC 24 V and switches AC loads in the voltage range of 24 V to 480 V with a load current of up to 25 A. The width is 22.5 mm, enabling compact mounting on DIN rail. The construction complies with standards IEC/EN 60947-4-2 and IEC/EN 60947-4-3, which apply to the safety and reliability of power semiconductor contactors.

Semiconductor contactor is the technical term for an electronic switching device that uses semiconductors (such as thyristors or triacs) instead of mechanical contacts to switch loads. This technology enables noiseless switching without mechanical wear. The BF9250.01/001 switches at zero voltage, meaning the circuit is opened or closed whenever the voltage passes through zero. This reduces electrical interference and extends the lifespan of the loads, especially with inductive loads such as motors.

Zero-voltage switching is a central function that synchronizes switching operations with the sinusoidal waveform of alternating voltage. This minimizes the generation of sparks and electrical overvoltages. Switching is performed via the control input X1, which operates with low current consumption and can therefore be directly controlled by a PLC (Programmable Logic Controller). This is particularly advantageous in automated systems where a direct interface to control devices is required.

Temperature monitoring is an integrated protection system that protects the power semiconductors from overheating. When a critical temperature is reached, an alarm output is activated, indicated by a red LED (J>). This enables early response to malfunctions or overloads. The monitoring is latching, meaning it remains active until the voltage at A1/A2 is briefly interrupted, allowing reset. This mechanism protects the device and connected loads from damage.

Alarm output is an integrated contact that is activated when the temperature monitoring triggers. It can be integrated into safety or monitoring systems to trigger, for example, an alarm message or shutdown. The combination of temperature monitoring and alarm output increases the safety and maintainability of the system.

Approvals and markings include UL listing C/US, confirming approval for use in the USA and Canada. Compliance with standards IEC/EN 60947-4-2 and IEC/EN 60947-4-3 ensures electrical safety and reliability of the device. Protection against transient overvoltages caused by switching operations or network disturbances is provided by varistors.

Compatibility and accessories include use in single- and multi-phase installations. The width of 22.5 mm allows mounting in standard DIN rail distribution boxes. The device is part of a product family that also includes 2-pole and 3-pole variants as well as wider widths (45 mm, 90 mm). Control via X1 makes it compatible with PLC systems. The load voltage up to 480 V and load current up to 50 A (in other variants) demonstrate the flexibility of the product series.

Mounting and installation is done by clipping onto a DIN rail, enabling quick and secure fixation in enclosures. Terminal markings (A1, A2, X1, T1, etc.) are standardized and facilitate wiring. LED indicators (green for operating voltage, yellow for X1 control, red for temperature alarm) support diagnostics during operation.

Operational advantages include noiseless switching, high semiconductor lifespan, integrated temperature protection, and direct PLC control. Zero-voltage switching reduces electrical interference and protects connected loads. UL listing and compliance with IEC standards guarantee suitability for safety-critical applications.

The device is suitable for use in industrial installations, building technology, and automation systems where reliable, low-maintenance, and disturbance-free switching of loads is required. The combination of electronic switching, temperature protection, and PLC-compatible control makes the BF9250.01/001 a robust and flexible component in modern control systems.

Technical data
ApprovalsUL
Load current up to50 A
Load voltage up toAC 480 V
Number of poles1-pole, 2-pole, 3-pole
On/Off Input ControlAC/DC, DC
Width22,5 mm, 45 mm, 90 mm
TypeBF 9250
Signalling outputYes
Temperature monitoringYes
Variant
Auxiliary voltageAC/DC 24 V
Contact equippingwith signal contact
Load currentAC 25 A
Load voltageAC 24 - 480 V
Semiconductor output1-pole
Approvals and MarkingsUL-listed C/US
VariantSwitching at zero crossing. Control input X1 with low current consumption. Monitoring output for the temperature protection


Product data sheet
Datasheet for Dold 0050518, EAN: 4030641505189

Questions & answers

What is the delivery time of Dold 0050518 BF9250.01/001 UH=DC24V AC25A semiconductor contactor AC24-480V ?

The article Dold 0050518 BF9250.01/001 UH=DC24V AC25A semiconductor contactor AC24-480V is currently not in stock and must be ordered on a per-order basis.

According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Dold 0050518 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Dold 0050518 BF9250.01/001 UH=DC24V AC25A semiconductor contactor AC24-480V always at the best possible price. We can give you a discount of 2% on Dold 0050518 BF9250.01/001 UH=DC24V AC25A semiconductor contactor AC24-480V if you choose payment in advance on ordering.

In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 5 pieces of Dold 0050518 BF9250.01/001 UH=DC24V AC25A semiconductor contactor AC24-480V we can offer you a price of 215,65 EUR per piece. The more you buy, the cheaper the article will be.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
