D-Link Switch DGS-1250-28X/E 24xGBit/4xSFP+ 48,3 cm ( 19 inch ) Managed
|
345,82 EUR |
|||||||||||
|
( 411,53 EUR incl. VAT ) ≈ £289.45 | ≈ $385.59 plus delivery charges: 55,00 € |
|||||||||||
| Delivery time from supplier's stock (ca.) 6 workdaysinfo_outline | |||||||||||
| In Stock: >10 pieces | |||||||||||
| End-Of-Life: | 09. Dec 2025 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Datasheet: | file_download Download | ||||||||||
| Lieske Part No.: | 1971737 | ||||||||||
| Mfg Part No: | DGS-1250-28X/E | ||||||||||
| UPC/EAN: | 0790069467875 | ||||||||||
| Weight: | 4 kg | ||||||||||
| Type: | CPNT | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for D-Link DGS-1250-28X/E:
D-Link's DGS-1250 Series Gigabit Smart Managed Switches with 10G uplinks are the latest generation of switches for higher PoE (Power over Ethernet) performance and high port density, multiple management interfaces and advanced Layer 2 features . With all of these features combined, the DGS-1250 series is a cost-effective and flexible solution to expand an expanding business network.
Highlights
- 24x Gigabit Ethernet port
- 4x 10G SFP+ port
- Switch capacity: 128 Gbps
- Full industry standard CLI, graphical web interface, console port
- Layer 2 and Layer 3 Lite features
- Switch
- ear category (ElektroG): relevant, Category 6: small IT and telecommunications devices, small IT and telecommunications devices B2C
- Integrated fan
- Switch type: Access
- Switching capacity: 128 GBit/s (Gbps)
- WEEE: 10490255
- Total number of copper ports: 24
- Total number of fiber optic ports: 4
- Bandwidth: 10/100/1000 MBit/s
- Console port
- Main port type: Copper
- Number of RJ45 ports (1G): 24
- Number of SFP+ ports (10G): 4
- Switch manageable: Yes
- Mounting type: 48,3 cm ( 19 inch ) rack mount
- IGMP
- Power supply: integrated
- Color: Black
- Height: 44 mm
- Length/depth: 140 mm
- Width: 440 mm
- Weight: 1750 g
- D-Link DGS-1250-28X 28-Port Smart Gigabit Switch 4x 10G
Product type
Specifications
Shipping
Connections
Functions
Power supply
Basic features
Scope of delivery
| Certificates | |
| Certification | CB, UL, BSMI, CCC |
| Data transmission | |
| Switching capacity | 128 Gbit/s |
| Forwarding rate | 95.24 Mpps |
| MAC address table | 16000 entries |
| Number of static routes | 124 |
| Jumbo frames | 12000 |
| Packet buffer memory | 12 MB |
| Store-and-forward | |
| Static route | |
| Jumbo frames support | |
| Design | |
| Product colour | Black |
| LED indicators | Activity, Link, Power, Speed |
| Electromagnetic compatibility | CE A, VCCI A, FCC A, IC, BSMI |
| Rack mounting | |
| Management features | |
| Switch type | Managed |
| Switch layer | L3 |
| MIB support | RFC2893, RFC4213, RFC4291, RFC2464, RFC2462, RFC4862, RFC2461, RFC4861, RFC2573, RFC1321, RFC2284, RFC2865, RFC2716, RFC3580, RFC826, RFC2463, RFC4443, RFC792, RFC793, RFC768, RFC791, RFC2389, RFC4113, RFC4022, RFC2618, RFC2674, RFC1398, RFC1643, RFC1650, RFC2358, RFC2665, RFC2021, RFC271, RFC1757, RFC2819, RFC1442, RFC1901, RFC1902, RFC1903, RFC1904, RFC1905, RFC1906, RFC1907, RFC1908, RFC2578, RFC3418, RFC2573, RFC2575, RFC2576, RFC1212, RFC1213, RFC1215, RFC1493, RFC1157, RFC2620, |
| Quality of Service (QoS) support | |
| Web-based management | |
| ARP inspection | |
| Configuring Location Settings (CLI) | |
| System event log | |
| Multicast features | |
| Multicast support | |
| Network | |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Cable types supported | Cat5, Cat5e |
| Virtual LAN features | Voice VLAN |
| Number of VLANs | 4094 |
| 10G support | |
| Port mirroring | |
| Full duplex | |
| Flow control support | |
| Link aggregation | |
| Broadcast storm control | |
| Auto MDI/MDI-X | |
| Spanning tree protocol | |
| Head-of-line (HOL) blocking | |
| VLAN support | |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Heat dissipation | 104.346 BTU/h |
| Optical fiber | |
| Fiber ethernet cabling technology | 100BASE-FX, 1000BASE-LHX, 1000BASE-X, 1000BASE‑LX, 1000BASE‑SX, 1000BASE‑ZX |
| Packaging data | |
| Package width | 282 mm |
| Package depth | 563 mm |
| Package height | 89 mm |
| Package weight | 2.97 kg |
| Performance | |
| Memory type | DDR3-SDRAM |
| Internal memory | 2048 MB |
| Flash memory | 64 MB |
| Noise level | 47.6 dB |
| Mean time between failures (MTBF) | 743482.45 h |
| Firmware upgradeable | |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP+ module slots quantity | 4 |
| Console port | RJ-45 |
| Power | |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 30.6 W |
| Power supply included | |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | |
| Security | |
| DHCP features | DHCP client, DHCP server, DHCP snooping |
| Access Control List (ACL) rules | 768 |
| Security algorithms | EAP, MD5, PEAP, SSH, SSL/TLS, TTLS |
| Queue scheduling algorithms | Weighted Round Robin (WRR) |
| Access Control List (ACL) | |
| IGMP snooping | |
| Loop protection | |
| IP-MAC-Port binding | |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 140 mm |
| Height | 44 mm |
| Weight | 3.86 kg |
Please note...
We have listed this article as 'end-of-life', which means that it will only be sold until it is completely sold out ! Please mind that we cannot guarantee you, you will receive the article, although it may be betokened as available. You can find the date from when the article was marked end-of-life to the top.
Questions & answers
What is the delivery time of D-Link Switch DGS-1250-28X/E 24xGBit/4xSFP+ 48,3 cm ( 19 inch ) Managed?
The article D-Link Switch DGS-1250-28X/E 24xGBit/4xSFP+ 48,3 cm ( 19 inch ) Managed is currently in stock
According to our experience the article is ready for dispatch within 6 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of D-Link DGS-1250-28X/E to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you D-Link Switch DGS-1250-28X/E 24xGBit/4xSFP+ 48,3 cm ( 19 inch ) Managed always at the best possible price. We can give you a discount of 2% on D-Link Switch DGS-1250-28X/E 24xGBit/4xSFP+ 48,3 cm ( 19 inch ) Managed if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 4 pieces of D-Link Switch DGS-1250-28X/E 24xGBit/4xSFP+ 48,3 cm ( 19 inch ) Managed we can offer you a price of 330,26 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
