D-Link DGS-1005D/E 5 Ports Ethernet Switch - 5 x Network (RJ-45) Ports - 10Base-T, 100/1000Base-T content_copy

This product is customized for use throughout Europe, except UK and Ireland. What it does? The DGS-1005D (Green Ethernet version) is an 5-port unmanaged Gigabit switch that consumes less energy than conventional switches of the same specification.This switch reacts when a device attached to it is turned off, by placing the corresponding port in a standby mode that requires less power. In addition, the switch is able to detect the Ethernet cable length and adjust power usage accordingly, hence saving any surplus power that would otherwise dissipate as heat. These two features combined can save up to 27% of the power used by the switch (figure based on a scenario assuming that PCs are used for 10 hours a day, powered off 14 hours a day and connected to the switch using 20m cables).This function allows the flow of data to be adjusted between switch and server, to ensure a reliable data transfer. At 2000 Mbps full duplex, the switch provides high-speed data pipes to your servers with minimum data transfer loss.All ports support auto-negotiation of MDI/MDIX cross over. This eliminates the need for cross over cables or uplink ports. Any port can simply plug to a server, a hub or a switch, using the usual straight-through twisted-pair cable.

Data transmission
Switching capacity	10 Gbit/s
MAC address table	2000 entries
Jumbo frames	9216
Packet forwarding rate (1 Gbps)	1488000 pps
Packet forwarding rate (100 Mbps)	148800 pps
Packet forwarding rate (10 Mbps)	14880 pps
Packet buffer memory	0.128 MB
Store-and-forward
Jumbo frames support
Design
Product colour	White
Housing material	Plastic
Rack mounting
LED indicators
Logistics data
Harmonized System (HS) code	85176990
Management features
Switch type	Unmanaged
Switch layer	L2
Quality of Service (QoS) support
Network
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
Ethernet LAN data rates	10,100,1000 Mbit/s
10G support
Full duplex
Auto MDI/MDI-X
MAC address auto-learning supported
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-10 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Packaging content
Manual
Performance
Mean time between failures (MTBF)	1142330 h
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power
DC input voltage	5 V
Input current	1 A
Power consumption (max)	2.01 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Weight & dimensions
Width	111 mm
Depth	75 mm
Height	30 mm
Weight	80 g

---
