CYBERPOWER OLS5KEA-IEC Double Conversion Online UPS 5000VA/4800W Rack/Tower 4U ECO Mode LCD USB Smart Slot for Optical Network Cards
|
2.257,20 EUR |
|||||||||||
|
( 2.686,07 EUR incl. VAT ) ≈ £1,905.08 | ≈ $2,528.06 plus delivery charges |
|||||||||||
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |||||||||||
| Lieske Part No.: | 1246157 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | OLS5KEA-IEC | ||||||||||
| UPC/EAN: | 4711027792026 | ||||||||||
| Weight: | 73 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Further UPS > 25000VA from CyberPowerFurther products in category UPS > 25000VA
All products of CyberPower
Product information for CyberPower OLS5KEA-IEC:
CyberPower OLS5KEA-IEC ist eine hocheffiziente USV mit Online-Doppelwandler-Topologie, die unterbrechungsfreie reine Sinuswellen-Stromversorgung für geschäftskritische Geräte wie NAS und Server, DVRs/Überwachungssysteme, Transport- und Infrastruktur- sowie Notfallsysteme bietet. Sie ist ideal für die Integration in Backoffice-, Serverraum- und RechenzentrumsumgebungenDie USV verfügt über einen hohen Ausgangsleistungsfaktor und liefert mehr nutzbare Leistung als eine herkömmliche USV. Das intuitive, neigbare Farb-LCD-Panel ermöglicht es Benutzern, das System einfach zu überwachen und die Einstellungen zu konfigurieren. Angeschlossene Batterieerweiterungsmodule (EBM) können automatisch erkannt werden, um die Laufzeit der USV zu berechnen. Außerdem kann der Batterieladestrom über die LCD-Einstellung angepasst werden, um die Ladezeit zu verkürzen. Ein Relais-Kontakt erlaubt spezifische USV-Ereignisbenachrichtigungen für eine einfache Verwaltung.Per USB oder optionaler Fernverwaltungskarte ist sie mit der PowerPanel Energieverwaltungssoftware kompatibel, um eine Echtzeitüberwachung und -Konfiguration durchzuführen.
Highlights
- Online (Doppelwandler) USV Topologie
- Hoher Ausgangsleistungsfaktor
- UPS Parallel Expansion (Optional)
- Wartungs-Bypass Schalter
- Automatische Erkennung externer Batteriemodule
- Kippbares LCD-Panel
- Notausschaltung (EPO) Anschluss
- Keine Umschaltzeit
- ECO Modus
- Versorgung mit reiner Sinuswelle
- Überlastschutz
- Konfigurierbarer Ladestrom
- Farb-LCD-Display
- Relais-Trockenkontakt
- PowerPanel Verwaltungssoftware
- SNMP / HTTP-Fernverwaltungsfähigkeit (optional)
- SNMP / HTTP-Fernverwaltungsfähigkeit (optional)
Produkttyp
- USV
- ear-Kategorie (ElektroG): relevant, Kategorie 5: Kleingeräte Spezifikationen
- Gehäusematerial: Metall
- Schutzfunktion: Überlast, Überspannung
- Bauform: Tower
- USV-Topologie: online
- typische Backupzeit bei voller Last: 5 min
- typische Backupzeit bei halber Last: 17 min
- Schaltzeit max: 0 ms
- akustische Signale
- Hot-Swap-fähig
Versand
- WEEE: 77251196
Anschlüsse
Display
- Displaytechnologie: LCD
- Display
Stromversorgung
- Ausgangskapazität: 5000 VA
- Eingangsbetriebsspannung min: 230 V
- Anzahl unterstützter Batterien: 10
- Ladezeit: 4 Stunde(n)
- Leistungsabgabe: 4800 W
Betriebsbedingungen
- Umgebungstemperatur Betrieb min: 0 °C
- Umgebungstemperatur Betrieb max: 40 °C
- Luftfeuchtigkeit Betrieb min: 0 %
- Luftfeuchtigkeit Betrieb max: 90 %
Grundeigenschaften
- Farbe: Schwarz
- Höhe: 520 mm
- Länge/Tiefe: 460 mm
- Breite: 270 mm
- Gewicht: 57 kg
Lieferumfang
- OLS5KEA-IEC USV
- USB-Kabel
- Benutzerhandbuch
- Schraubensatz
- Kaltgeräteverlängerung
- USB-Kabel
- Benutzerhandbuch
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Typical backup time at full load | 5.3 min |
| Typical backup time at half load | 17 min |
| Battery recharge time | 4 h |
| Charging current | 4 A |
| Hot-swap battery | |
| Certificates | |
| Compliance certificates | CE, RoHS |
| Design | |
| Form factor | Tower |
| Housing material | Metal |
| Rack capacity | 4U |
| Cooling type | Active |
| Product colour | Black |
| Control type | Buttons |
| Display type | LCD |
| Built-in fan | |
| LED indicators | |
| Features | |
| UPS topology | Double-conversion (Online) |
| Output power capacity | 5 kVA |
| Output power | 4800 W |
| Waveform | Pure sine |
| Input operation voltage (min) | 110 V |
| Input operation voltage (max) | 300 V |
| Input frequency | 50/60 Hz |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Output frequency | 50/60 Hz |
| Output frequency regulation | 0.5 Hz |
| Output voltage regulation | 1% |
| Maximum current | 25 A |
| Surge energy rating | 1335 J |
| Number of input phases | 1 |
| Number of output phases | 1 |
| Efficiency (ECO mode) | 98% |
| Input power factor | 0.99 |
| Output power factor | 0.96 |
| Power Factor Correction (PFC) type | Active |
| Crest factor | 3:1 |
| Total Harmonic Distortion (THD) (linear load) | 1.5% |
| Total Harmonic Distortion (THD) (non-linear load) | 2% |
| Power source type | AC |
| ECO mode | |
| Emergency Power Off (EPO) | |
| EMI/RFI noise filtering | |
| Audible alarm(s) | |
| Detachable power cord | |
| Socket circuit breaker | |
| Logistics data | |
| Country of origin | China |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 1500 m |
| Non-operating altitude | 0 - 15000 m |
| Other features | |
| Nominal input voltage | 230 V |
| Quantity of delay expansion units (max) | 4 |
| Overload protection | |
| Packaging content | |
| Batteries included | |
| Quick installation guide | |
| Packaging data | |
| Package width | 350 mm |
| Package depth | 721 mm |
| Package height | 566 mm |
| Package weight | 70.4 kg |
| Package type | Box |
| Ports & interfaces | |
| AC outlet types | C13 coupler, C19 coupler, Terminal |
| Power plug | Terminal |
| AC outlets quantity | 11 AC outlet(s) |
| USB 2.0 ports quantity | 1 |
| USB port type | USB Type-B |
| Serial interface type | RS-232 |
| USB port | |
| Serial interface | |
| Emergency Power Off (EPO) connector | |
| SmartSlot | |
| Sustainability | |
| Sustainability compliance | |
| Weight & dimensions | |
| Width | 270 mm |
| Depth | 520 mm |
| Height | 460 mm |
| Weight | 57 kg |
Please note...
This article has over-weight and though needs to be transported by a forwarding agency. Please mind, that the calculation of the delivery charges in the shopping cart disregard this aspect.
Though, there will be corresponding surcharges after you send us your order.
