BlackBox LGC5184C-R3 GIGABIT TX/SX850MM

MCII 1000 Card

High-Density Media Conversion System II - 1000Mbps Ethernet Card for the Media Converter System II

Converts 1000Base-TX to 1000Base-SX or LX.
Supports distances up to 40 kilometers.
Available in multimode and single-mode versions.
Supports LinkLoss and FiberAlert functions.
Warranty: 6-Year Double Diamond™ (Standard)

1.25-Gbps Ethernet – Perfect for Gigabit applications in enterprise and service provider networks, this SNMP-manageable card converts Gigabit twisted-pair signals to 1000BASE-SX or 1000BASE-LX fiber optics.

High Availability
Fiber connections usually link critical network locations and carry large amounts of data, making them some of the most important connections within a network. The Media Converter System II is a top choice for network administrators. This modular system includes media converter cards that can be hot-swapped into a chassis serving as a central hub.

Ultimate Connectivity
The High-Density Media Converter System II offers versatility for various applications, supporting modules for Ethernet, Fast Ethernet, Gigabit Ethernet, T1/E1, ATM OC-3, ATM OC-12, Fibre Channel, and protocol-independent fiber-to-fiber conversions. This range includes switched media converter modules and WDM single-strand fiber modules for high-performance connections.

Switched Media Conversion and WDM Advantages
Switched media converter modules handle media, speed, and duplex conversion, enabling end devices with different speeds and duplex modes to connect. Using Layer 2 technology, frames are processed using a store-and-forward technique with address filtering. The WDM module doubles existing fiber capacity or, in new installations, halves costs by using a single fiber strand, supporting 1310 nm and 1550 nm wavelengths over the same fiber. Supports up to 40 kilometers.

Management and Monitoring
The Media Converter System II includes an SNMP agent embedded on the chassis backplane, with environmental sensors for temperature and voltage monitoring. SNMP software, iView, is included with the chassis.

Link Integrity and Auto-Crossover
LinkLoss™ and FiberAlert™ features simplify monitoring and troubleshooting fiber links. LinkLoss mimics a physical connection, dropping the copper link when fiber link loss occurs (FX LinkLoss and TX LinkLoss). FiberAlert monitors the fiber link and halts transmission if signal loss occurs, informing the remote side. With LinkLoss and FiberAlert, the management system keeps you updated on connection status and fault location, reducing downtime and simplifying troubleshooting.

Connections

• LMC5184C (Set of Two Modules)
• 1000BASE-T: RJ-45, 100 m
• 1000BASE-SX: 2 x SC, SM; 1310 nm, 9 µm, 15 km

Management

• Indicators: Per Port: Speed, Link Activity, FDX/HDX
• Interface: SNMP MIB I, II; iView software for Windows® (GUI)

Engine (WDM, Converter)

• Conversion Technique: Layer 1: Transparent; Layer 2: Store and Forward, Address Filtering
• Fiber Link Detection: FiberAlert, remote notification
• Link Loss Detection: Copper and fiber
• VLAN Tagging: Transparent pass-through
