Aten Video Switch, 3xInput(HDMI/VGA/HDBaseT), 2xOutput(HDMI/HDBaseT), 4 x 2 True 4K presentation, DSP and HDBaseT-Lite
|
-21% 855,25 EUR 1.088,42 EUR |
|
|
( 1.017,75 EUR incl. VAT ) ≈ £720.12 | ≈ $960.45 plus delivery charges: 53,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1782031 |
| Mfg Part No: | VP1421 |
| UPC/EAN: | 4719264649158 |
| Weight: | 2.5 kg |
Product information for Aten VP1421:
| Design | |
| Housing colour | Black |
| Housing material | Metal |
| Control type | Buttons, Rotary |
| On/off switch | |
| Remote control included | |
| Display | |
| Built-in display | |
| Features | |
| Product type | Scaling matrix switcher |
| Maximum resolution | 4096 x 2160 pixels |
| HDCP version | 2.2 |
| HDCP | |
| 3D | |
| High Dynamic Range (HDR) supported | |
| Extended display identification data (EDID) | |
| Logistics data | |
| Products per master (outer) case | 3 pc(s) |
| Master (outer) case gross weight | 7.25 kg |
| Master (outer) case length | 427 mm |
| Master (outer) case width | 370 mm |
| Master (outer) case height | 232 mm |
| Master (outer) case net weight | 4.74 kg |
| Harmonized System (HS) code | 85299097 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
| Heat dissipation | 110 BTU/h |
| Packaging content | |
| Manual | |
| AC adapter included | |
| IR receiver included | |
| Ports & interfaces | |
| HDMI input ports quantity | 2 |
| HDMI output ports quantity | 1 |
| VGA (D-Sub) input ports | 1 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Remote (IR) output | 1 |
| Remote (IR) input | 1 |
| DC-in jack | |
| Power | |
| Power consumption (typical) | 14.93 W |
| Technical data | |
| Length packaging | 0.414m |
| Inputs x outputs | 4x2 |
| Packaging volume | 0.0100m³ |
| Width packaging | 0.207m |
| Weight | 2.200kg |
| Interface | HDMI+multi format |
| Height packaging | 0.117m |
| Weight & dimensions | |
| Width | 170.1 mm |
| Depth | 200 mm |
| Height | 44 mm |
| Weight | 1.58 kg |
| Package width | 207 mm |
| Package depth | 414 mm |
| Package height | 117 mm |
| Package weight | 2.2 kg |
Questions & answers
What is the delivery time of Aten Video Switch, 3xInput(HDMI/VGA/HDBaseT), 2xOutput(HDMI/HDBaseT), 4 x 2 True 4K presentation, DSP and HDBaseT-Lite?
The article Aten Video Switch, 3xInput(HDMI/VGA/HDBaseT), 2xOutput(HDMI/HDBaseT), 4 x 2 True 4K presentation, DSP and HDBaseT-Lite is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Aten VP1421 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Aten Video Switch, 3xInput(HDMI/VGA/HDBaseT), 2xOutput(HDMI/HDBaseT), 4 x 2 True 4K presentation, DSP and HDBaseT-Lite always at the best possible price. We can give you a discount of 2% on Aten Video Switch, 3xInput(HDMI/VGA/HDBaseT), 2xOutput(HDMI/HDBaseT), 4 x 2 True 4K presentation, DSP and HDBaseT-Lite if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
