Aten KVM switch 16x VGA / USB / TP, LAN (IP-capable), 1xlocal + 4x Remote User, with Audio & Virtual Media Support
|
7.135,71 EUR 7.135,71 EUR |
|
|
( 8.491,49 EUR incl. VAT ) ≈ £5,972.59 | ≈ $7,956.32 plus delivery charges: 100,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 837326 |
| Mfg Part No: | KN4116V |
| UPC/EAN: | 4710423778535 |
| Weight: | 7 kg |
Product information for Aten KN4116V:
| Design | |
| Rack capacity | 1U |
| Product colour | Metallic |
| Housing material | Metal |
| LED indicators | Link, Power |
| Rack mounting | |
| Cascadable | |
| Push button | |
| Hot keys | |
| Display | |
| Built-in display | |
| Logistics data | |
| Master (outer) case net weight | 6.63 kg |
| Master (outer) case width | 506 mm |
| Master (outer) case length | 575 mm |
| Master (outer) case height | 130 mm |
| Master (outer) case gross weight | 7.63 kg |
| Products per master (outer) case | 1 pc(s) |
| Network | |
| Ethernet LAN (RJ-45) ports | 20 |
| Cabling technology | 10/100/1000Base-T(X) |
| Security algorithms | FIPS 140-2 |
| Ethernet LAN | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Packaging content | |
| Cables included | AC |
| Manual | |
| Rack mount kit | |
| Packaging data | |
| Package width | 521 mm |
| Package depth | 570 mm |
| Package height | 152 mm |
| Package weight | 7.63 kg |
| Performance | |
| HD type | WUXGA |
| Maximum resolution | 1920 x 1200 pixels |
| Video bandwidth | 60 Hz |
| Scan interval | 1,255 s |
| Ports & interfaces | |
| Number of computers controlled | 16 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DVI-D/VGA |
| DVI-D ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Console ports | DVI-D, RJ–45, USB A, VGA (D-Sub) |
| Console USB ports quantity | 2 |
| USB 2.0 Type-A hub ports quantity | 3 |
| USB connector type | Mini-USB B, USB Type-A |
| Serial port type | RJ-45 |
| Serial ports quantity | 1 |
| Headphone outputs | 1 |
| Number of microphone inputs | 1 |
| USB hub | |
| Audio connections | |
| DC-in jack | |
| Power | |
| Power source | AC |
| Input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1 A |
| Weight & dimensions | |
| Width | 433.6 mm |
| Depth | 412.1 mm |
| Height | 44 mm |
| Weight | 6.63 kg |
Questions & answers
What is the delivery time of Aten KVM switch 16x VGA / USB / TP, LAN (IP-capable), 1xlocal + 4x Remote User, with Audio & Virtual Media Support?
The article Aten KVM switch 16x VGA / USB / TP, LAN (IP-capable), 1xlocal + 4x Remote User, with Audio & Virtual Media Support is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Aten KN4116V to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Aten KVM switch 16x VGA / USB / TP, LAN (IP-capable), 1xlocal + 4x Remote User, with Audio & Virtual Media Support always at the best possible price. We can give you a discount of 2% on Aten KVM switch 16x VGA / USB / TP, LAN (IP-capable), 1xlocal + 4x Remote User, with Audio & Virtual Media Support if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
