ATEN KL1516AN KVM-Switch 48cm TFT VGA PS/2-USB over Kat 5 16 Port D
|
1.797,29 EUR |
|
|
( 2.138,78 EUR incl. VAT ) ≈ £1,513.32 | ≈ $2,018.36 plus delivery charges: 148,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 148079 |
| Mfg Part No: | KL1516AN-AXA-XG |
| UPC/EAN: | 4710469344114 |
| Weight: | 18.8 kg |
| Display | |
| Display diagonal | 48.3 cm (19") |
| Display resolution | 1280 x 1024 pixels |
| Display | LCD |
| Display brightness | 250 cd/m² |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 160° |
| Pixel pitch | 0.294 x 0.294 mm |
| Display type | TFT |
| Response time | 5 ms |
| Display number of colours | 16.7 million colours |
| Supported resolutions | 1600 x 1200 @ 60Hz (non-FHD version) 1920 x 1200 @ 60Hz (FHD version) |
| On Screen Display (OSD) | |
| Keyboard | |
| Keyboard language | German |
| Keyboard layout | QWERTZ |
| Built-in touchpad | |
| Hot keys | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Packaging content | |
| Cables included | AC, KVM |
| Quick installation guide | |
| Manual | |
| Rack mount kit | |
| Ports & interfaces | |
| VGA (D-Sub) ports quantity | 1 |
| I/O ports | 1x DB-25 1x RJ-11 |
| Keyboard port type | USB, PS/2 |
| Mouse port type | USB, PS/2 |
| Video port type | VGA |
| RJ-45 ports quantity | 18 |
| USB 2.0 Type-A ports quantity | 3 |
| Power | |
| AC adapter input voltage | 100 - 240 V |
| AC adapter frequency | 50/60 Hz |
| Input current | 1 A |
| AC (power) in | |
| System requirements | |
| Windows operating systems supported | |
| Mac operating systems supported | |
| Linux operating systems supported | |
| Technical details | |
| Material | Metal |
| Product colour | Black |
| Operating relative humidity (H-H) | 0 - 80% |
| KVM switch ports quantity | 8 |
| Maximum resolution | 1920 x 1200 pixels |
| Console port | VGA/USB/PS2 |
| Number of computers controlled | 256 |
| Auto scan delay (min) | 1 s |
| Auto scan delay (max) | 255 s |
| Compliance certificates | RoHS |
| Rack capacity | 1U |
| Built-in KVM switch | |
| Rack mounting | |
| Daisy chain | |
| On/off switch | |
| LED indicators | |
| Push button | |
| Weight & dimensions | |
| Width | 701.2 mm |
| Height | 44 mm |
| Depth | 480 mm |
| Weight | 15.4 kg |
Questions & answers
What is the delivery time of ATEN KL1516AN KVM-Switch 48cm TFT VGA PS/2-USB over Kat 5 16 Port D?
The article ATEN KL1516AN KVM-Switch 48cm TFT VGA PS/2-USB over Kat 5 16 Port D is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Aten KL1516AN-AXA-XG to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you ATEN KL1516AN KVM-Switch 48cm TFT VGA PS/2-USB over Kat 5 16 Port D always at the best possible price. We can give you a discount of 2% on ATEN KL1516AN KVM-Switch 48cm TFT VGA PS/2-USB over Kat 5 16 Port D if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
