APC Easy UPS 3S 10kVA 400V 3:3 UPS Low Tower
|
4.773,75 EUR |
|
|
( 5.680,76 EUR incl. VAT ) ≈ £4,052.91 | ≈ $5,380.02 plus delivery charges |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Lieske Part No.: | 1697085 |
|---|---|
| Mfg Part No: | E3SUPS10KH |
| UPC/EAN: | 0731304339328 |
| Weight: | 50 kg |
| Type: | ACCS |
Product information for APC E3SUPS10KH:
| Certificates | |
| Certification | CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE |
| Design | |
| Form factor | Tower |
| Product colour | White |
| International Protection (IP) code | IP20 |
| Features | |
| UPS topology | Double-conversion (Online) |
| Output power capacity | 10 kVA |
| Output power | 10000 W |
| Waveform | Pure sine |
| Input operation voltage (min) | 304 V |
| Input operation voltage (max) | 477 V |
| Input frequency | 45/65 Hz |
| Output operation voltage (min) | 380 V |
| Output operation voltage (max) | 415 V |
| Output frequency | 50/60 Hz |
| Maximum current | 18 A |
| Number of input phases | 3 |
| Number of output phases | 3 |
| Input power factor | 0.99 |
| Crest factor | 3:1 |
| Overload capacity (10 minutes) | 125% |
| Overload capacity (1 minute) | 150% |
| Output voltage Total Harmonic Distortion (THD) | 3% |
| Input current Total Harmonic Distortion (THD) | 3% |
| Noise level | 60 dB |
| Power protection features | Overload |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 984.3 m |
| Non-operating altitude | 0 - 14763.6 m |
| Other features | |
| Output voltage | 400 V |
| Packaging content | |
| Management card included | |
| Quick installation guide | |
| Packaging data | |
| Package width | 400 mm |
| Package depth | 700 mm |
| Package height | 772 mm |
| Package weight | 50 kg |
| Ports & interfaces | |
| AC outlet types | Hardwire |
| SmartSlot | |
| SmartConnect port | |
| Weight & dimensions | |
| Width | 250 mm |
| Depth | 700 mm |
| Height | 530 mm |
| Weight | 36 kg |
Questions & answers
What is the delivery time of APC Easy UPS 3S 10kVA 400V 3:3 UPS Low Tower?
The article APC Easy UPS 3S 10kVA 400V 3:3 UPS Low Tower is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of APC E3SUPS10KH to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you APC Easy UPS 3S 10kVA 400V 3:3 UPS Low Tower always at the best possible price. We can give you a discount of 2% on APC Easy UPS 3S 10kVA 400V 3:3 UPS Low Tower if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
