ALLNET PoE injector Gigabit / PoE & PoE+ (15.4W/30W)/ 2.5Gbit/ metal housing / ALL0489v4

The ALL0489v4 2.5GBASE-T PoE+ Injector offers up to 30 watts of power and a 2.5 gigabit data connection anywhere in the network infrastructure. This device injects DC power over a CAT5e UTP cable, increasing flexibility in positioning a PoE-enabled device when a nearby power source is missing. It supports the PoE+ standard (802.3af 15.4W The device is plug-and-play without software configuration. It supports an operating temperature of 0 C° - 45 C° and has a metal housing design, which is more suitable for various environmental applications. An easily recognizable PoE LED status signal signals the PoE connection status. To ensure safety, the device has overcurrent and short circuit protection
for connection to the Ethernet switch 10/100 /1000/2500 Base-T PoE (Power/Data) for connecting to the PoE device (PD) Auto-Negotiation Automatic detection of whether the connected device is PoE capable to allow sending power to a non-PoE device Complies with the IEEE802.3, 802.3u, 802.3ab, 802.3bz, 802.3bz, 802.3af, 802.3at 802.3af (15.4W) and 802.3at (30W) standards -Screw full range (100~240VAC) Internal power supply No fan, passive cooling, small size, silent design MTBF: over 50,000 hours@45 C° ESD IEC61000-4-2 contact +/-4KV, air +/-8KV EFT IEC61000- 4-4-4 Power 2KV, LAN 1KV Overload protection IEC61000 4-5 Cable to cable PRODUCT SPECIFICATIONSStandard IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3bz, IEEE802.3af, IEEE802.3at Standards Interface: 1 * PoE+ 10/ 100/1000/2500Mbps RJ-45 port, 1 * 10/100/1000/2500Mbps RJ-45 port LED indicators: Power (green), PoE link (green) Emission: FCC, CE, VCCI Class B Security: CE LVD operating temperature Storage temperature Dimensions: 130 x 62 x 36 mm Switching power supply: +54V/40W, 100~240VAC input, 47~63Hz. Overload protection
