Allied Telesis AT-X230-18GP-50 ALLIED L2+ managed switch 16x 10/100/1000Mbps POE ports 2x SFP uplink slots 1 Fixed AC power supply
|
1.118,60 EUR |
|||||||||||
|
( 1.331,13 EUR incl. VAT ) ≈ £948.57 | ≈ $1,253.95 plus delivery charges: 53,00 € |
|||||||||||
| Made to order · Expected to be available from 15.04.2027info_outline | |||||||||||
| Lieske Part No.: | 896713 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | AT-X230-18GP-50 | ||||||||||
| UPC/EAN: | 0767035202662 | ||||||||||
| Weight: | 4.27 kg | ||||||||||
| Type: | CPNT | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Allied Telesis AT-X230-18GP-50:
| Certificates | |
| Certification | UL, cUL, UL-EU |
| Data transmission | |
| Switching capacity | 36.6 Gbit/s |
| Throughput | 26.8 Mpps |
| MAC address table | 16000 entries |
| Packet buffer memory | 1.5 MB |
| Jumbo frames support | |
| Design | |
| Product colour | Grey |
| Safety | UL60950-1, CAN/CSA-C22.2 No. 60950-1-03, EN60950-1, EN60825-1, AS/NZS 60950.1 |
| Rack mounting | |
| LED indicators | |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Management features | |
| Switch type | Managed |
| Switch layer | L2+ |
| MIB support | RFC1212, RFC1213, RFC1227, RFC1239, RFC2011, RFC2012, RFC2013, RFC2096, RFC2819, RFC2863, RFC3418, RFC3621, RFC3636 |
| Quality of Service (QoS) support | |
| Web-based management | |
| System event log | |
| Multicast features | |
| Multicast support | |
| Network | |
| Networking standards | IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-T, 10BASE-T |
| 10G support | |
| Port mirroring | |
| Full duplex | |
| Flow control support | |
| Link aggregation | |
| Broadcast storm control | |
| Auto MDI/MDI-X | |
| Spanning tree protocol | |
| VLAN support | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Non-operating altitude | 0 - 3048 m |
| Heat dissipation | 168 BTU/h |
| Packaging data | |
| Package weight | 4.2 kg |
| Performance | |
| Internal memory | 256 MB |
| Flash memory | 64 MB |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 2 |
| Console port | RJ-45 |
| Power connector | DC-in jack |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 21 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) ports quantity | 16 |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Total Power over Ethernet (PoE) budget | 296 W |
| Power over Ethernet (PoE) | |
| Protocols | |
| Management protocols | IGMP, MLD, Telnet, SMTP, NTP |
| Supported network protocols | SNTP |
| Security | |
| DHCP features | DHCPv6 client, DHCP client |
| Security algorithms | EAP-TTLS, MD5, PEAP, SSL/TLS |
| IGMP snooping | |
| Weight & dimensions | |
| Width | 341 mm |
| Depth | 231 mm |
| Height | 44 mm |
| Weight | 3 kg |
