VDE-Kabel 502420400000 19G2, 5 sq mm, Heavy rubber cable
|
23,94 EUR |
|||||||||||
|
incl. 3,42 EUR copper surcharge ( 28,49 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 482237 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 502420400000 | ||||||||||
| Weight: | 0 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for VDE-Kabel 502420400000:
according to VDE 0282-4
Application:
For connection of equipment under very extreme
Loads, both mechanical and thermal point of view.
For example, for equipment used in agricultural, industrial and fire-hazard
ten operating sites. Next they are for large boilers, heating plates,
Hand lamps, electric tools such as circular saws, drills,
Home network devices, but also for transportable motors or machines
used on construction sites or farms, etc.,
can also be used for fixed installation, eg on plaster, in temporary
Buildings and barracks, allowed for direct laying aud components
of lifting equipment, machinery, etc.
Building:
Conductor: Stranded bare copper Class 5
Insulation: rubber compound according to VDE 0207 T. 20
Core identification according to VDE 0293
Outer sheath: rubber compound according to VDE 0207 T. 21
Color: black
Specifications:
Rated voltage: 450/750 V
Test voltage: 2500 V
Temperature range: - 25 ° C - + 60 ° C (during installation)
- 40 ° C - +60 ° C (after installation)
Operating temp. +60 ° C (max.)
Bending radius: 6 x cable diameter (min.)
Dauerzugbelastung: max. 15N/mm 2 taking into account the
Total copper cross section
Fire: according to VDE 0472 T. 804
Category B (= IEC 332-1)
Oil resistance of sheath: VDE 0472 T. 803 Category A
Ozone resistance: according to VDE 0472 T. 805 Category A or
according to VDE 0472 T. 805 A1 Category C
Number of cores x cross-section mm ² 1 x 25
Copper content (kg / m%): 24.0
Outer diameter approx: 15.8
Weight (kg / m%): 36.9
Type: H07RN-F 19G2, 5 TR
Quantity: 1 MTR
Type: H07RN-F 19G2,5 TR
The final cable weight will be determined before invoicing. The calculation is based on the copper content and any additional weight due to drums, pallets, or outer packaging. Prices are subject to this subsequent calculation.
Please note that for cables, that are not in stock and must be produced, the manufacturer may need an order of a minimum length that can be 5-10km depending on cable type!
