UBIQUITI NETWORKS UDR7 Ubiquiti Dream Router 7 • UniFi OS Console Full Stack • 2,3 Gbps IDS/IPS • 1x SFP+ • 4x 2,5 GbE • 30+ Devices • WIFI7 • BE10600 •
|
282,65 EUR |
|
|
( 336,35 EUR incl. VAT ) ≈ £236.30 | ≈ $312.33 plus delivery charges: 55,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Lieske Part No.: | 1246028 |
|---|---|
| Mfg Part No: | UDR7 |
| UPC/EAN: | 8101771602126 |
| Weight: | 1.7 kg |
Product information for UBIQUITI NETWORKS UDR7:
The Ubiquiti Dream Router 7 (UDR7) is a desktop 10G cloud gateway designed as a central network control unit for small to medium-sized businesses as well as demanding home applications. The device combines in a compact polycarbonate housing an integrated WiFi 7 access point, a PoE switch, a microSD storage, and full UniFi application support. It serves as a gateway for managing up to 30 UniFi devices and supports more than 300 clients simultaneously. Device management is performed via the UniFi OS Console, accessible through Ethernet and Bluetooth interfaces.
Applications
The UDR7 is suitable for networks requiring a central, centrally managed infrastructure, particularly in offices, small business networks, or residences with high demands for network speed and security. The integrated WiFi 7 functionality with 6 GHz band support enables high data rates and low latency, which is beneficial for streaming, video conferencing, and IoT applications. Support for IPv6-ISP and SD-WAN functions expands its usability in modern networks.
Functions and Equipment in Detail
The device features an integrated 6-stream WiFi-7 AP with support for 2.4 GHz, 5 GHz, and 6 GHz bands. Maximum transmit power is 22 dBm in the 2.4 GHz band, 26 dBm in the 5 GHz band, and 23 dBm in the 6 GHz band. Antenna gains are 5 dBi (2.4 GHz), 7 dBi (5 GHz), and 6 dBi (6 GHz). Throughput rates reach up to 688 Mbit/s in the 2.4 GHz band (BW40), 4.3 Gbit/s in the 5 GHz band (BW240), and 5.7 Gbit/s in the 6 GHz band (BW320). MIMO technology supports 2x2 DL/UL MU-MIMO across all bands. WLAN standards include 802.11a/b/g/n/ac/ax/be, with security provided by WPA-PSK and WPA-Enterprise (WPA/WPA2/WPA3/PPSK). Support for 4 BSSIDs per radio enables flexible network segmentation.
Technology Explained Simply
The UDR7 is equipped with a Quad-Core Arm® Cortex® A53 processor at 1.5 GHz and 3 GB DDR4 system memory. The network interface includes three 2.5-GbE RJ45 LAN ports, one 10G SFP+ WAN port, and an additional 2.5-GbE RJ45 WAN port. An integrated PoE port (Pair A 1, 2+ 3, 6-) provides a maximum PoE power of 15.4 W per port in PoE mode (voltage range 44–57 V DC). Power supply is via an internal AC/DC adapter with 50 W power, supporting a universal input range of 100–240 V AC at 50/60 Hz. Maximum power consumption is 26 W (excluding PoE output). A 64 GB microSD storage is pre-installed and expandable.
Compatibility and Accessories
The device is compatible with the UniFi OS Console and requires UniFi Network Software version 9.0.108 or later. It supports management of more than 30 UniFi devices and more than 300 simultaneous clients. The integrated firewall offers application-based rules, signature-based IPS/IDS threat detection, content, country, domain, and advertisement filtering, as well as VLAN/subnet-based traffic segmentation. Additional features include WireGuard, L2TP, OpenVPN server and client, Site-to-Site VPN, Teleport, and Identity VPN. The IDS/IPS throughput performance is 2.3 Gbit/s.
Mounting and Installation
The UDR7 is designed as a desktop device and is placed on a flat surface. Installation is performed via the UniFi OS Console, accessible through Ethernet or Bluetooth. Configuration is done via the web interface of the UniFi software. Device management is possible via the cloud or locally. Operating temperature ranges from -10 °C to 40 °C, and operating humidity is 5 to 95 % (non-condensing). The device features a 2,4 cm ( 1 inch )-LCM display, a factory reset button, and white/blue illuminated LEDs for status indication.
Operational Advantages
The UDR7 offers a central management solution for complex networks with high demands for speed, security, and scalability. The integrated WiFi 7 technology enables high data rates and low latency. Support for PoE and SD-WAN extends functionality. UniFi application support enables centralized device management and monitoring. IDS/IPS functions provide enhanced security. The 64 GB microSD storage allows logging and configuration storage. The 2.5 GbE and 10G SFP+ ports ensure high bandwidth in the network.
Certifications
The device is certified according to CE, FCC, and IC, confirming compliance with European and North American electromagnetic compatibility and safety standards.
Operating Environment
The UDR7 is designed for indoor use. Operating temperature ranges from -10 °C to 40 °C, and operating humidity is 5 to 95 % (non-condensing). The device is not intended for outdoor use.
Software and Network Functions
The software supports WLAN standards 802.11a/b/g/n/ac/ax/be, including WLAN 6/6E and WLAN 7. Wireless security includes WPA-PSK and WPA-Enterprise (WPA/WPA2/WPA3/PPSK). VLAN support follows 802.1Q. Advanced QoS functions enable per-user rate limiting and guest traffic isolation. Support for IPv6-ISP and SD-WAN functions enhances network flexibility.
Additional Functions
The device offers a full stateful firewall, policy-based WAN and VPN routing, DHCP relay, customizable DHCP server, IGMP proxy, and LTE backup support as a failover option. Reporting on internet quality and outages enables proactive network monitoring.
Display and Operation
A 2,4 cm ( 1 inch )-LCM screen displays status information. A factory reset button allows resetting to default settings. White and blue LEDs indicate operational status.
Housing and Dimensions
The device has a round cross-section with a diameter of 110 mm and a height of 184.1 mm. The housing is made of polycarbonate and weighs 1.1 kg.
Certifications
The device is certified according to CE, FCC, and IC, confirming compliance with European and North American electromagnetic compatibility and safety standards.
Operating Environment
The UDR7 is designed for indoor use. Operating temperature ranges from -10 °C to 40 °C, and operating humidity is 5 to 95 % (non-condensing). The device is not intended for outdoor use.
Software and Network Functions
The software supports WLAN standards 802.11a/b/g/n/ac/ax/be, including WLAN 6/6E and WLAN 7. Wireless security includes WPA-PSK and WPA-Enterprise (WPA/WPA2/WPA3/PPSK). VLAN support follows 802.1Q. Advanced QoS functions enable per-user rate limiting and guest traffic isolation. Support for IPv6-ISP and SD-WAN functions enhances network flexibility.
Additional Functions
The device offers a full stateful firewall, policy-based WAN and VPN routing, DHCP relay, customizable DHCP server, IGMP proxy, and LTE backup support as a failover option. Reporting on internet quality and outages enables proactive network monitoring.
Display and Operation
A 2,4 cm ( 1 inch )-LCM screen displays status information. A factory reset button allows resetting to default settings. White and blue LEDs indicate operational status.
Housing and Dimensions
The device has a round cross-section with a diameter of 110 mm and a height of 184.1 mm. The housing is made of polycarbonate and weighs 1.1 kg.
Applications
The UDR7 is suitable for networks requiring a central, centrally managed infrastructure, particularly in offices, small business networks, or residences with high demands for network speed and security. The integrated WiFi 7 functionality with 6 GHz band support enables high data rates and low latency, which is beneficial for streaming, video conferencing, and IoT applications. Support for IPv6-ISP and SD-WAN functions expands its usability in modern networks.
Functions and Equipment in Detail
The device features an integrated 6-stream WiFi-7 AP with support for 2.4 GHz, 5 GHz, and 6 GHz bands. Maximum transmit power is 22 dBm in the 2.4 GHz band, 26 dBm in the 5 GHz band, and 23 dBm in the 6 GHz band. Antenna gains are 5 dBi (2.4 GHz), 7 dBi (5 GHz), and 6 dBi (6 GHz). Throughput rates reach up to 688 Mbit/s in the 2.4 GHz band (BW40), 4.3 Gbit/s in the 5 GHz band (BW240), and 5.7 Gbit/s in the 6 GHz band (BW320). MIMO technology supports 2x2 DL/UL MU-MIMO across all bands. WLAN standards include 802.11a/b/g/n/ac/ax/be, with security provided by WPA-PSK and WPA-Enterprise (WPA/WPA2/WPA3/PPSK). Support for 4 BSSIDs per radio enables flexible network segmentation.
Technology Explained Simply
The UDR7 is equipped with a Quad-Core Arm® Cortex® A53 processor at 1.5 GHz and 3 GB DDR4 system memory. The network interface includes three 2.5-GbE RJ45 LAN ports, one 10G SFP+ WAN port, and an additional 2.5-GbE RJ45 WAN port. An integrated PoE port (Pair A 1, 2+ 3, 6-) provides a maximum PoE power of 15.4 W per port in PoE mode (voltage range 44–57 V DC). Power supply is via an internal AC/DC adapter with 50 W power, supporting a universal input range of 100–240 V AC at 50/60 Hz. Maximum power consumption is 26 W (excluding PoE output). A 64 GB microSD storage is pre-installed and expandable.
Compatibility and Accessories
The device is compatible with the UniFi OS Console and requires UniFi Network Software version 9.0.108 or later. It supports management of more than 30 UniFi devices and more than 300 simultaneous clients. The integrated firewall offers application-based rules, signature-based IPS/IDS threat detection, content, country, domain, and advertisement filtering, as well as VLAN/subnet-based traffic segmentation. Additional features include WireGuard, L2TP, OpenVPN server and client, Site-to-Site VPN, Teleport, and Identity VPN. The IDS/IPS throughput performance is 2.3 Gbit/s.
Mounting and Installation
The UDR7 is designed as a desktop device and is placed on a flat surface. Installation is performed via the UniFi OS Console, accessible through Ethernet or Bluetooth. Configuration is done via the web interface of the UniFi software. Device management is possible via the cloud or locally. Operating temperature ranges from -10 °C to 40 °C, and operating humidity is 5 to 95 % (non-condensing). The device features a 2,4 cm ( 1 inch )-LCM display, a factory reset button, and white/blue illuminated LEDs for status indication.
Operational Advantages
The UDR7 offers a central management solution for complex networks with high demands for speed, security, and scalability. The integrated WiFi 7 technology enables high data rates and low latency. Support for PoE and SD-WAN extends functionality. UniFi application support enables centralized device management and monitoring. IDS/IPS functions provide enhanced security. The 64 GB microSD storage allows logging and configuration storage. The 2.5 GbE and 10G SFP+ ports ensure high bandwidth in the network.
Certifications
The device is certified according to CE, FCC, and IC, confirming compliance with European and North American electromagnetic compatibility and safety standards.
Operating Environment
The UDR7 is designed for indoor use. Operating temperature ranges from -10 °C to 40 °C, and operating humidity is 5 to 95 % (non-condensing). The device is not intended for outdoor use.
Software and Network Functions
The software supports WLAN standards 802.11a/b/g/n/ac/ax/be, including WLAN 6/6E and WLAN 7. Wireless security includes WPA-PSK and WPA-Enterprise (WPA/WPA2/WPA3/PPSK). VLAN support follows 802.1Q. Advanced QoS functions enable per-user rate limiting and guest traffic isolation. Support for IPv6-ISP and SD-WAN functions enhances network flexibility.
Additional Functions
The device offers a full stateful firewall, policy-based WAN and VPN routing, DHCP relay, customizable DHCP server, IGMP proxy, and LTE backup support as a failover option. Reporting on internet quality and outages enables proactive network monitoring.
Display and Operation
A 2,4 cm ( 1 inch )-LCM screen displays status information. A factory reset button allows resetting to default settings. White and blue LEDs indicate operational status.
Housing and Dimensions
The device has a round cross-section with a diameter of 110 mm and a height of 184.1 mm. The housing is made of polycarbonate and weighs 1.1 kg.
Certifications
The device is certified according to CE, FCC, and IC, confirming compliance with European and North American electromagnetic compatibility and safety standards.
Operating Environment
The UDR7 is designed for indoor use. Operating temperature ranges from -10 °C to 40 °C, and operating humidity is 5 to 95 % (non-condensing). The device is not intended for outdoor use.
Software and Network Functions
The software supports WLAN standards 802.11a/b/g/n/ac/ax/be, including WLAN 6/6E and WLAN 7. Wireless security includes WPA-PSK and WPA-Enterprise (WPA/WPA2/WPA3/PPSK). VLAN support follows 802.1Q. Advanced QoS functions enable per-user rate limiting and guest traffic isolation. Support for IPv6-ISP and SD-WAN functions enhances network flexibility.
Additional Functions
The device offers a full stateful firewall, policy-based WAN and VPN routing, DHCP relay, customizable DHCP server, IGMP proxy, and LTE backup support as a failover option. Reporting on internet quality and outages enables proactive network monitoring.
Display and Operation
A 2,4 cm ( 1 inch )-LCM screen displays status information. A factory reset button allows resetting to default settings. White and blue LEDs indicate operational status.
Housing and Dimensions
The device has a round cross-section with a diameter of 110 mm and a height of 184.1 mm. The housing is made of polycarbonate and weighs 1.1 kg.
| General | |
| Degree of protection | not specified |
| Operating voltage | 100–240 V AC |
| Maximum power consumption | 26 W |
| PoE budget | 15,4 W |
| PoE voltage range | 44–57 V DC |
| Processor | Quad-Core Arm® Cortex® A53 1.5 GHz |
| System memory | 3 GB DDR4 |
| microSD storage | 64 GB |
| WLAN standards | 802.11a/b/g/n/ac/ax/be |
| WLAN bands | 2.4 GHz, 5 GHz, 6 GHz |
| Max. transmit power 2.4 GHz | 22 dBm |
| Max. transmit power 5 GHz | 26 dBm |
| Max. transmit power 6 GHz | 23 dBm |
| Antenna gain 2.4 GHz | 5 dBi |
| Antenna gain 5 GHz | 7 dBi |
| Antenna gain 6 GHz | 6 dBi |
| Throughput rate 2.4 GHz | 688 Mbit/s |
| Throughput rate 5 GHz | 4,3 Gbit/s |
| Throughput rate 6 GHz | 5,7 Gbit/s |
| MIMO (Multiple-Input Multiple-Output ) | 2 x 2 (DL/UL MU-MIMO) |
| IDS/IPS throughput | 2,3 Gbit/s |
| LAN ports | 3 2.5-GbE-RJ45 |
| WAN ports | 2 1x 10G-SFP+, 1x 2.5-GbE-RJ45 |
| PoE port | 1 Pair A 1, 2+ 3, 6- |
| Current supply | Internal AC/DC, 50 W |
| Operation temperature | -10 to 40 °C |
| Air humidity | 5 to 95 % non-condensing |
| Certifications | CE, FCC, IC |
| Housing material | Polycarbonate |
| LCM display | 0,96" |
| Button | Factory reset |
| LEDs | White/Blue |
| Software requirement | UniFi Network version 9.0.108 and higher |
