TP-Link RE365 AC1200 WLAN Repeater
|
48,56 EUR 49,19 EUR |
|
|
( 57,79 EUR incl. VAT ) ≈ £40.45 | ≈ $53.27 plus delivery charges: 55,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1427557 |
| Mfg Part No: | RE365 |
| UPC/EAN: | 6935364083991 |
| Weight: | 0.27 kg |
| Type: | WRLS |
Product information for TP-Link RE365:
Applications
The repeater is suitable for use in private households and small offices where uniform WLAN coverage across multiple rooms or floors is required. It is particularly useful in larger apartments, houses, or buildings with multiple storeys, where the WLAN signal from the main router does not reach all areas adequately. The maximum possible transmission range is 3048 m, although the actual range may vary depending on the environment, building materials, and electromagnetic interference. The integrated signal indicator helps find the optimal location for the repeater by visually displaying the current signal strength.
Functions and Equipment in Detail
The RE365 features two internal antennas for optimal signal distribution. The transmit power is between 6.5 and 18 dBm in CE mode and between 8 and 19 dBm in FCC mode. The WPS function allows for quick and secure network configuration with a single button press. The LED indicators can be turned off, which facilitates use in dark rooms or during nighttime operation. An on/off switch and a reset button are also integrated to simplify operation and restore settings.
Technology Explained Simply
The repeater operates in Access Point Mode and wirelessly connects to the main router. In this mode, it functions as an additional WLAN access point, receiving the signal from the main router, amplifying it, and forwarding it to other devices. The Ethernet LAN interface (RJ-45) also enables the connection of wired devices such as Smart TVs, gaming consoles, or Blu-ray players to the WLAN, with the repeater acting as a WLAN adapter. Power supply is provided via an integrated socket, freeing up an additional socket for other devices. The power supply operates on an AC voltage of 100 to 240 V at a frequency of 50/60 Hz, with a power consumption of 8 W in standard operation.
Compatibility and Accessories
The repeater is universally compatible with all WLAN routers and access points supporting the standards 802.11a/b/g/n/ac. It is designed for operating systems such as Windows 10, 7, 8, 8.1, 2000, XP, Vista, NT, 98SE, Mac OS, and Linux. Configuration is performed via a web browser (supported browsers: Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0) or via the TP-Link Tether app for Android and iOS devices. The app allows control of power settings, LED indicators, network names, and passwords. Configuration is accessible via the web address http://tplinkrepeater.net or http://192.168.0.254.
Installation and Mounting
Installation is performed by connecting the repeater to a socket near the main router. Configuration can be done via the Tether app or a web browser. After setup, the repeater is placed at an optimal location, ideally halfway between the router and the target device, to ensure the best possible signal transmission. The quick start guide included in the package supports easy setup.
Advantages in Operation
The RE365 provides a reliable and fast WLAN connection in previously poorly covered areas. The integrated socket increases flexibility, as no additional socket is required for the repeater’s power supply. The LED indicators and the Tether app simplify positioning and remote control. Support for WPA/WPA2-PSK and WEP (64-bit, 128-bit) ensures a secure network connection. The operating temperature ranges from 0 to 40 °C, and the relative humidity during operation is 10 to 90 %, enabling use in normal indoor environments. Dimensions are 125 mm (height) × 70 mm (width) × 77 mm (depth), and the colour is white. Conformity certifications CE and RoHS are certified.
| Antenna | |
| Antennas quantity | 2 |
| Antenna type | Internal |
| Transmitting power (CE) | 6.5 - 18 dBm |
| Transmitting power (FCC) | 8 - 19 dBm |
| Certificates | |
| Compliance certificates | CE, RoHS |
| Design | |
| Product colour | White |
| LED indicators | |
| On/off switch | |
| Reset button | |
| Network | |
| Cabling technology | 10/100Base-T(X) |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi data rate (max) | 867 Mbit/s |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA2-PSK |
| Wi-Fi | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Packaging content | |
| Quick start guide | |
| Packaging data | |
| Package type | Box |
| Package width | 171 mm |
| Package depth | 104 mm |
| Package height | 99 mm |
| Package weight | 380 g |
| Performance | |
| Type | Network repeater |
| Maximum transfer distance | 3048 m |
| Data transfer rate | 867 Mbit/s |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Windows operating systems supported | Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
| Browser supported | Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 |
| WPS push button | |
| Mac compatibility | |
| Mac operating systems supported | |
| Linux operating systems supported | |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (typical) | 8 W |
| Weight & dimensions | |
| Width | 70 mm |
| Depth | 77 mm |
| Height | 125 mm |
Questions & answers
What is the delivery time of TP-Link RE365 AC1200 WLAN Repeater ?
The article TP-Link RE365 AC1200 WLAN Repeater is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of TP-Link RE365 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you TP-Link RE365 AC1200 WLAN Repeater always at the best possible price. We can give you a discount of 2% on TP-Link RE365 AC1200 WLAN Repeater if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
