TP-Link WLAN router M7450 4G LTE SIM card slot/display content_copy

With the mobile router M7450 4G/LTE WLAN from TP-Link you can enjoy fast internet everywhere. The M7450 supports LTE-A (CAt.6) through carrier aggregation. With this technology, LTE frequencies that are distant from each other are combined into a virtual band and the data throughput is increased up to 300 Mbit/s. The M7450 supplies up to 32 WLAN devices via UMTS or LTE connection.
The powerful 3000 mAh battery enables up to 15 hours of mains-independent work and up to 900 hours in standby. The integrated MicroSD slot makes it even easier to share music, videos and photos. Management is carried out conveniently via the app, so that you can set data limits, monitor the transfer and check the connected devices at any time and without any problems. You can also send messages and save data on the optional MicroSD card.

Highlights

• Supports LTE/Cat6 with up to 300 Mbit/s in download and 50 Mbit/s in upload
• Simultaneous surfing for up to 32 users/devices
• 300 Mbit/s on the 2.4 GHz and 867 Mbit/s on 5 GHz band
• For uninterrupted HD streaming and online gaming
• The rechargeable 3000 mAh battery provides energy for up to 15 hours of mains-independent operation
• Micro SD card slot for up to 32 GB of additional storage space
• Easy management with the tpMiFi App
• All important information at a glance thanks to the display
• Slim and light design for on the go

Product type

• Mobile router
• ear category (ElektroG): relevant, Category 6: small IT and telecommunications devices, Small IT devices and telecommunications technology B2C

Functions

• Hotspot

Data transmission

• WLAN standard: IEEE 802.11b - WiFi 1, IEEE 802.11g - WiFi 3, IEEE 802.11n - WiFi 4
• Security standard: WPA, WPA2

Basic properties

• Color: black, gray
• Height: 16 mm
• Length/Depth: 66.5 mm
• Width: 112.5 mm

Scope of delivery

• Mobile 300Mbit/s WLAN LTE router M7450
• Micro USB cable
• Nano to micro SIM adapter
• 3000 mAh - Battery
• Quick Installation Guide

Battery
Battery capacity	3000 mAh
Certificates
Certification	CE, RoHS
Design
Device type	Cellular network router
Product colour	Black, Grey
Market positioning	Portable
Display type	TFT
Display diagonal	3.66 cm (1.44")
Built-in display
Reset button
LED indicators
Ethernet LAN features
Ethernet LAN
DHCP client
DHCP server
Logistics data
Harmonized System (HS) code	85176990
Mobile network
Data network	Edge, GPRS, GSM, HSPA, LTE, UMTS
2G standards	Edge, GPRS
3G standards	DC-HSDPA, HSPA, HSPA+, UMTS
4G standard	LTE-TDD & LTE-FDD
2G bands supported	850,900,1800,1900 MHz
3G bands supported	900,2100 MHz
4G bands supported	800,900,1800,2100,2600 MHz
GSM bands supported	850,900,1800,1900 MHz
UMTS bands supported	900,2100 MHz
Number of simultaneous SIM cards	1
Operational conditions
Operating temperature (T-T)	0 - 35 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Packaging content
Cables included	Micro-USB
Packaging data
Package width	149 mm
Package depth	101 mm
Package height	60 mm
Package weight	260 g
Performance
Antenna type	Internal
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP
Mac operating systems supported
Ports & interfaces
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
USB port
Card reader integrated
Power
Power source type	Battery
Security
Security algorithms	WPA-PSK, WPA2-PSK
Weight & dimensions
Width	112 mm
Depth	65 mm
Height	16 mm
Wireless LAN features
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
WLAN data transfer rates supported	300 Mbit/s
Wi-Fi

---
