TP-LINK 5 Port Gigabit Multi-WAN Router (bis 4xWAN) 1xSFP content_copy

Professional VPN router with load balancing and central SDN integration. As a gateway that seamlessly integrates into the Omada SDN (Omada Software Defined Networking), the ER7206 can be managed centrally from anywhere and at any time. Standalone management via the web interface or app is also possible to maximize flexibility. One Gigabit SFP WAN port, one Gigabit RJ45 WAN port and two freely interchangeable WAN/LAN ports allow the router to support up to four WAN ports to meet various Internet access requirements with one router fulfill. The Multi-WAN Load Balancing feature distributes transmissions according to the bandwidth share of each WAN port, thereby optimizing bandwidth utilization across multiple Internet accesses.

Highlights

• Integrated into Omada SDN: zero-touch provisioning (ZTP), centralized cloud management and intelligent monitoring
• Centralized management: cloud access and Omada app for convenience and easy management
• Gigabit ports: 1 Gigabit SFP - and 5 Gigabit RJ45 ports provide high-speed wired connections
• Up to 4 WAN ports: 1 Gigabit SFP WAN port, 1 Gigabit RJ45 WAN port, 2 Gigabit WAN/LAN ports optimize bandwidth usage
• Highly secure VPN: Supports up to 100× LAN-to-LAN IPSec, 50× OpenVPN, 50× L2TP and 50× PPTP VPN connections
• Numerous security features: Advanced firewall policies, DoS defense, IP/MAC/ URL filtering and other security functions protect your network and your data

Product type

• stationary router
• ear category (ElektroG): relevant, category 6: small IT and telecommunications technology devices, small IT and telecommunications technology devices B2C

Specifications

• Area of application: Indoor

Connections

• Total number of copper ports: 5
• Total number of fiber optic ports: 1

Functions

• DHCP server
• VPN
• UTM Functionality: VPN support, translation of network addresses (NAT)
• wall mountable

Data transmission

• Bandwidth: 10 /100/1000 MBit/s

Basic features

• Color: Black
• Height: 35 mm
• Length/Depth: 131 mm
• Width: 226 mm

Scope of delivery

• TP-Link ER7206 SafeStream Gigabit Multi-WAN VPN Router
• Power cable
• Quick start guide

Design
Product colour	Black
LED indicators
Features
Flash memory	128 MB
Internal memory	512 MB
Internal memory type	DDR4
Management features
Web-based management
Universal Plug and Play (UPnP)
Reset button
Network
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3q, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ethernet interface type	Gigabit Ethernet
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10,100,1000 Mbit/s
Static route
VLAN support
Port forwarding
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Ports & interfaces
Ethernet LAN (RJ-45) ports	5
SFP module slots quantity	1
USB ports quantity	1
USB version	3.2 Gen 1 (3.1 Gen 1)
DC-in jack
Power
Output voltage	12 V
Output current	1 A
Protocols
DHCP client
DHCP server
Security
Security algorithms	SNMP, SNMPv2, SNMPv3
VPN tunnels quantity	50
WAN connection
Ethernet WAN
DSL WAN
SIM card slot
3G/4G USB modem compatibility
SFP WAN
Weight & dimensions
Width	226 mm
Depth	131 mm
Height	35 mm

---
