TP-LINK ER707-M2 Omada Multi-Gigabit VPN Router
|
146,28 EUR 146,29 EUR |
|
|
( 174,07 EUR incl. VAT ) ≈ £122.29 | ≈ $161.64 plus delivery charges: 55,00 € |
|
| Delivery time from supplier's stock (ca.) 6 workdaysinfo_outline | |
| In Stock: >100 pieces | |
| End-Of-Life: | 10. Sep 2026 |
|---|---|
| Datasheet: | file_download Download |
| Lieske Part No.: | 2082423 |
| Mfg Part No: | ER707-M2(UN) |
| UPC/EAN: | 4895252500738 |
| Weight: | 1.52 kg |
| Type: | WRLS |
Product information for TP-Link ER707-M2(UN):
The TP-Link Omada ER707-M2 is a stationary VPN Router with Multi-Gigabit capability, specifically designed for use in small and medium enterprises as well as in retail, hotels, and offices. The device offers a powerful network connection with up to six WAN ports, enabling flexible and scalable broadband usage. The 2.5 Gigabit Ethernet interfaces ensure high data transfer rates, with the WAN connection available via Ethernet or SFP ports. The integrated Omada Software Defined Networking (SDN) platform enables centralized, cloud-based network management, allowing configuration, monitoring, and maintenance of multiple locations through a unified interface.
Applications
The router is designed for indoor use and is particularly suitable for environments requiring a stable, secure, and scalable network infrastructure. Support for load balancing across multiple WAN connections increases broadband channel utilization and provides redundant connectivity. The integrated centralized management via the Omada platform enables remote device management, making network administration more efficient. Features such as Zero-Touch Provisioning (ZTP) and intelligent network monitoring support quick setup and continuous network monitoring.
Functions and Equipment in Detail
The ER707-M2 features six RJ45 ports, with one port designated as a dedicated 2.5G-WAN port, another as a 2.5G-WAN/LAN port, and four as Gigabit-WAN/Llan ports. Additionally, a Gigabit SFP port is integrated, enabling fiber optic connections. A USB 2.0 port supports the use of USB storage devices and allows connection of an LTE modem as a backup link. The web-based management interface provides an intuitive user interface for configuring and monitoring the router. Features such as DHCP server, DHCP client, NAT, URL filtering, and access control lists support network security and management.
Technology Explained Simply
The router is equipped with a dual-core ARMv8 processor, ensuring high processing performance. The 1 GB DDR4 memory allows simultaneous processing of up to 500,000 sessions, suitable for networks with high usage intensity. The flash memory size is 128 MB, sufficient to store the operating system and firmware updates. Power supply is provided via an external power adapter rated at 12 V / 1.5 A, ensuring stable energy supply. The fanless design ensures quiet operation, which is advantageous in office environments. The 4 kV surge protection function protects the device against voltage spikes and enhances reliability.
Compatibility and Accessories
The router is compatible with various SFP modules, including the MiniGBIC module 1 GBit SFP LC Singlemode LX TL-SM311LS and the Multimode SX TL-SM311LM. The use of ISP Bridge Modem GPON GBIC ONT ALL-BM510-GPON-GBIC enables integration into GPON networks. The Omada platform supports management of access points, switches, and gateways, enabling consistent network management across different devices. Support for VPN protocols such as IPSec, PPTP, L2TP, OpenVPN, SSL VPN, and GRE VPN enables secure connections between locations or for remote work.
Mounting and Installation
The device is wall-mountable and can be installed in standard 19-inch racks or on walls. Installation is performed using the included quick installation guide. LED indicators for LAN, WAN, system, USB, power, and speed facilitate status monitoring. The reset button allows resetting to factory defaults. The operating temperature ranges from 0 to 40 °C, enabling use in typical indoor environments.
Operational Advantages
The ER707-M2 offers high throughput of up to 1.44 Gbit/s and supports policy-based routing as well as static routes. VLAN support enables logical separation of network segments. Security features include ICMP attack prevention, DoS protection, IP/MAC filtering, and URL filtering. System event logging allows tracking of network events. Support for Windows, Mac, and Linux operating systems ensures broad compatibility. Compliance with CE, FCC, and RoHS ensures adherence to applicable standards.
Scope of Delivery
The router is delivered with an AC power adapter, a power cable, and a quick installation guide. The packaging includes the device and all necessary components for initial setup.
Applications
The router is designed for indoor use and is particularly suitable for environments requiring a stable, secure, and scalable network infrastructure. Support for load balancing across multiple WAN connections increases broadband channel utilization and provides redundant connectivity. The integrated centralized management via the Omada platform enables remote device management, making network administration more efficient. Features such as Zero-Touch Provisioning (ZTP) and intelligent network monitoring support quick setup and continuous network monitoring.
Functions and Equipment in Detail
The ER707-M2 features six RJ45 ports, with one port designated as a dedicated 2.5G-WAN port, another as a 2.5G-WAN/LAN port, and four as Gigabit-WAN/Llan ports. Additionally, a Gigabit SFP port is integrated, enabling fiber optic connections. A USB 2.0 port supports the use of USB storage devices and allows connection of an LTE modem as a backup link. The web-based management interface provides an intuitive user interface for configuring and monitoring the router. Features such as DHCP server, DHCP client, NAT, URL filtering, and access control lists support network security and management.
Technology Explained Simply
The router is equipped with a dual-core ARMv8 processor, ensuring high processing performance. The 1 GB DDR4 memory allows simultaneous processing of up to 500,000 sessions, suitable for networks with high usage intensity. The flash memory size is 128 MB, sufficient to store the operating system and firmware updates. Power supply is provided via an external power adapter rated at 12 V / 1.5 A, ensuring stable energy supply. The fanless design ensures quiet operation, which is advantageous in office environments. The 4 kV surge protection function protects the device against voltage spikes and enhances reliability.
Compatibility and Accessories
The router is compatible with various SFP modules, including the MiniGBIC module 1 GBit SFP LC Singlemode LX TL-SM311LS and the Multimode SX TL-SM311LM. The use of ISP Bridge Modem GPON GBIC ONT ALL-BM510-GPON-GBIC enables integration into GPON networks. The Omada platform supports management of access points, switches, and gateways, enabling consistent network management across different devices. Support for VPN protocols such as IPSec, PPTP, L2TP, OpenVPN, SSL VPN, and GRE VPN enables secure connections between locations or for remote work.
Mounting and Installation
The device is wall-mountable and can be installed in standard 19-inch racks or on walls. Installation is performed using the included quick installation guide. LED indicators for LAN, WAN, system, USB, power, and speed facilitate status monitoring. The reset button allows resetting to factory defaults. The operating temperature ranges from 0 to 40 °C, enabling use in typical indoor environments.
Operational Advantages
The ER707-M2 offers high throughput of up to 1.44 Gbit/s and supports policy-based routing as well as static routes. VLAN support enables logical separation of network segments. Security features include ICMP attack prevention, DoS protection, IP/MAC filtering, and URL filtering. System event logging allows tracking of network events. Support for Windows, Mac, and Linux operating systems ensures broad compatibility. Compliance with CE, FCC, and RoHS ensures adherence to applicable standards.
Scope of Delivery
The router is delivered with an AC power adapter, a power cable, and a quick installation guide. The packaging includes the device and all necessary components for initial setup.
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
| Sustainability compliance | |
| Design | |
| Product colour | Black |
| Housing material | Steel |
| LED indicators | LAN, Link, Power, Speed, System, USB, WAN |
| Wall mountable | |
| Features | |
| Flash memory | 128 MB |
| Internal memory | 1000 MB |
| Internal memory type | DDR4 |
| Windows operating systems supported | Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
| Mac operating systems supported | |
| Linux operating systems supported | |
| Management features | |
| Web-based management | |
| Universal Plug and Play (UPnP) | |
| Reset button | |
| Network | |
| Networking standards | IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3q, IEEE 802.3u, IEEE 802.3x |
| Ethernet interface type | 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Throughput | 1.44 Gbit/s |
| Static route | |
| VLAN support | |
| Policy-based routing | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Packaging content | |
| AC adapter included | |
| Quick installation guide | |
| Packaging data | |
| Package width | 242 mm |
| Package depth | 323 mm |
| Package height | 73 mm |
| Package weight | 1.1 kg |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 6 |
| WAN/Ethernet LAN ports quantity | 6 |
| WAN ports quantity | 1 |
| Installed SFP modules quantity | 1 |
| USB ports quantity | 1 |
| USB version | 2.0 |
| Power | |
| Power source type | DC |
| Output voltage | 12 V |
| Output current | 1.5 A |
| Protocols | |
| Supported network protocols | TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP |
| DMZ support | |
| DHCP client | |
| DHCP server | |
| Security | |
| Security algorithms | 3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1, SNMP, SNMPv2, SNMPv3 |
| VPN tunnels quantity | 66 |
| URL filtering | |
| ICMP attack prevention | |
| Access Control List (ACL) | |
| Network address translation (NAT) | |
| System event log | |
| WAN connection | |
| Ethernet WAN | |
| SFP WAN | |
| Weight & dimensions | |
| Width | 226 mm |
| Depth | 131 mm |
| Height | 35 mm |
