Softing IT Networks WX_AC_6A_REFPCCORD1,228037 Softing, WireXpert zbh. Cat. 6A reference patch cable (1 piece) content_copy

This product is a Cat. 6A reference patch cable from Softing IT Networks, specifically developed for testing CAT 6A patch cable adapters. It serves as a calibration and test reference in the field of network measurement technology, to validate the functionality and performance of adapters for high-speed network cables. The cable is part of the WireXpert product family and is used in professional environments where the accuracy of network tests is critical.

Reference patch cable for CAT 6A adapters
The cable functions as a standard reference object to check the measurement results of CAT 6A adapters. This ensures that the adapters operate correctly and do not cause any deviations in signal transmission. Using a reference cable enables a reproducible and verifiable test environment, which is necessary for quality assurance in network infrastructure.

Applications
The reference patch cable is primarily used in the installation, maintenance, and diagnosis of structured cabling systems. It is suitable for users working with WireXpert network test devices who need to verify the reliability of their CAT 6A adapters. The application occurs in professional IT and electrical installations, particularly during the setup of Gigabit and 10-Gigabit Ethernet networks, where high data rates and low signal distortion are required.

Functions and equipment in detail
The cable is delivered as a single unit (1 piece) and meets the requirements of Category 6A. It is used for calibration and validation of patch cable adapters to ensure that these do not introduce additional errors or signal losses. The cable’s construction is designed to represent the specific electrical and mechanical properties of CAT 6A cables, simulating realistic test conditions.

Technology explained simply
A reference patch cable is a calibrated cable serving as a known standard. When testing a CAT 6A adapter, the reference cable is connected and its measured values (such as impedance, attenuation, NEXT, ACR) are compared with expected values. Deviations indicate a defective or faulty adapter. Using such a cable increases the reliability of test results by eliminating external error sources.

Compatibility and accessories
The cable is specifically designed for use with CAT 6A patch cable adapters used in conjunction with WireXpert network test devices. It is not a universal cable, but serves exclusively as a reference for the specified application. Compatibility is limited to the specific adapter models offered by Softing IT Networks for the WireXpert platform.

Installation and mounting
Installation is performed by simply connecting the reference patch cable to the CAT 6A adapter being tested. No additional tools or special mounting procedures are required. The use is part of the test procedure and typically occurs in the laboratory or on-site at the network infrastructure. Handling is straightforward, as the cable serves only as a measurement reference and is not integrated into the network traffic.

Operational advantages
Using a reference patch cable enables an objective evaluation of adapter performance. This reduces error rates in network tests and lowers maintenance costs by avoiding falsely identified faults. The cables are standardized, ensuring test repeatability and supporting quality assurance in network projects.

General
Cable category	6A

---
