Softing IT Networks FX_INSP_LCPC-APC,216575 Softing, WireXpert, e.g. Switchable adapter for FiberXpert 5000 LC/PC, LC/APC content_copy

The switchable adapter from manufacturer Softing IT Networks, type WX_FX_INSP_LCPC-APC, is an accessory for the fiber optic microscope FiberXpert 5000. It is designed to adapt to different fiber optic connectors and enables inspection of LC/PC and LC/APC connectors within a single device. The switchable feature allows the user to alternate between the two common connector types without requiring an additional adapter. This is particularly advantageous in environments with mixed fiber installations, as inspection can be performed without changing tools.

Fiber optic microscope accessories such as this adapter are designed for visual inspection of fiber cables and connectors. Inspection is carried out using optical magnification, enabling the detection of contamination, damage, or insufficient polishing quality on the fiber end faces. Using a switchable adapter reduces the need for multiple individual adapters and simplifies the workflow during maintenance and installation of fiber optic systems.

Functions and equipment in detail
This adapter is specifically developed for use with the FiberXpert 5000 and enables adaptation to LC/PC and LC/APC connectors. The switching mechanism is mechanical, allowing the user to select between the two connector types without replacing the device or adapter. This is especially useful in environments where both PC and APC connectors are used, such as in data centers or during FTTH network installations. The design ensures secure and precise positioning of the connector for clear optical inspection.

Technology explained simply
LC connectors (Lucent Connector) are a standard connection in fiber optic communication. The designations PC (Physical Contact) and APC (Angled Physical Contact) refer to the shape of the fiber end face. PC connectors have a flat, polished end face, while APC connectors feature an angled polished end face to minimize reflections. These differences require specific adapters to ensure correct inspection. The switchable adapter from Softing allows both variants to be inspected with a single device, thereby increasing the efficiency of inspection tasks.

Compatibility and accessories
The adapter is designed exclusively for the fiber optic microscope FiberXpert 5000. It is not a universal accessory but specifically adapted to the interfaces and mechanics of this device. Use with other devices is not intended and may cause malfunctions.

Mounting and installation
Installation is performed directly onto the fiber optic microscope FiberXpert 5000. The adapter is inserted into the device, with the switching function activated via a mechanical switch or sliding mechanism. Installation is carried out by simply inserting the adapter and switching its position to activate the desired connector type.

Advantages in operation
Using the switchable adapter reduces the need for multiple individual adapters, simplifying inventory and logistics. Inspections can be performed more quickly, as no adapter change is required. This is particularly beneficial for network maintenance where various connector types are present. The mechanical switching ensures reliable and precise positioning of the fiber end face, securing the quality of the inspection.

Batteries are not included in the delivery scope.
