Softing IT Networks FX_AC_AD_DIN,216571 Softing DIN Universal Adapter for FiberXpert OTDR DIN socket for FiberXpert MM and SM measurements

Your rating:
Average rating
product review for Softing IT Networks FX_AC_AD_DIN,216571 Softing DIN Universal Adapter for FiberXpert OTDR DIN socket for FiberXpert MM and SM measurements
( 4.5 / 5 ) 2 ratings
Softing IT Networks FX_AC_AD_DIN,216571
This image may differ from the desired article.
287,28 EUR 288,18 EUR
( 341,86 EUR incl. VAT )
≈ £240.17  |  ≈ $315.72
plus delivery charges: 55,00 €
Delivery time from supplier's stock (ca.) 20 workdaysinfo_outline
1x Softing IT Networks FX_AC_AD_DIN,216571 Softing DIN Universal Adapter for FiberXpert OTDR DIN socket for FiberXpert MM and SM measurements
Lieske Part No.:539690
Mfg Part No: FX AC AD DIN,216571
UPC/EAN: 0046382254204
Weight:1 kg
Type:FX_AC_AD_ST

Product information for Softing IT Networks FX_AC_AD_DIN,216571:

The DIN Universal Adapter from Softing IT Networks, type FX_AC_AD_ST, is a specific accessory for the FiberXpert OTDR, designed for connection to DIN sockets in field installations. It enables measurements on fiber optic cables, both in multimode (MM) and singlemode (SM) ranges, and is thus suitable for a wide range of applications in optical network testing. The adapter is configured as an ST socket, representing a standardized connector for fiber optic cables, commonly used in older or industrial networks.

Applications

The adapter is used in optical measurement technology, particularly during the installation, maintenance, and diagnosis of fiber optic cables. It serves as an interface between the FiberXpert OTDR and a DIN connector installed in the network, allowing measurements to be performed directly at the existing connection point. This is especially advantageous in environments where direct access to the cable end is not possible, such as in distribution boxes or on industrial devices with DIN sockets. Using the adapter reduces the need for additional adapter cables or intermediate connectors, thereby increasing measurement efficiency.

Functions and Equipment in Detail

The DIN Universal Adapter is designed as a universal accessory suitable for both multimode and singlemode measurements. The ST socket is a mechanically robust connector that ensures a secure and precise optical coupling. The connection is made via a cylindrical plug with a key, which fits into the socket, ensuring accurate alignment of the fiber cores. The adapter is specifically developed for use with the FiberXpert OTDR, ensuring compatible and reliable integration into the measurement system.

Technology Explained Simply

The adapter functions as a mechanical and optical interface between the FiberXpert OTDR measurement device and a DIN connector installed in the network. OTDR technology (Optical Time Domain Reflectometry) allows analysis of fiber optic cables by evaluating reflected light, with the adapter ensuring the light signal is transmitted from the device into the cable. The ST socket enables a stable and repeatable connection, which is essential for precise measurement results. The adapter’s universality for MM and SM means it can be used regardless of the fiber type, increasing flexibility in application.

Compatibility and Accessories

The adapter is specifically developed for the FiberXpert OTDR from Softing IT Networks and is used directly with this device. It is configured as an ST socket, representing a standard connection in fiber optic infrastructure. Compatibility with MM and SM fibers enables application in various networks, whether in local area networks (LAN), industrial facilities, or telecommunications infrastructures.

Installation and Mounting

Installation is performed by simply inserting the adapter into the DIN socket of the network. The adapter is directly connected to the FiberXpert OTDR, with the connection established via the integrated ST socket. Installation requires no additional tools or special preparations, as the connector is mechanically stable and easy to handle. The adapter is used on-site without requiring additional adapter cables or intermediate connectors.

Operational Advantages

Using the DIN Universal Adapter reduces the number of required connection components and minimizes potential sources of error during measurement. Direct connection to the existing DIN socket enables quick and reliable diagnosis of fiber optic cables. The universality for MM and SM measurements increases flexibility and reduces the need for multiple specific adapters. The mechanical robustness of the ST socket ensures long service life and reliable performance even under industrial conditions.

General
Adapter typeDIN universal adapter
CompatibilityMM and SM
Suitable forFiberXpert OTDR
