Schmersal TESK-SU-12ST1 hinge safety switch 103005763
|
131,98 EUR |
|||||||||||
|
( 157,06 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 1326360 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 103005763 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Schmersal 103005763:
Technical Data:
Product Designation:
- TESK-SU-12ST1
Article Number:
- 103005763
EAN:
- 4030661435756
eCl@ss Numbers:
- Version 12.0: 27-27-06-09
- Version 11.0: 27-27-06-09
- Version 9.0: 27-27-06-09
ETIM Numbers:
- Version 7.0: EC002591
- Version 6.0: EC002591
Approvals - Regulations:
- Certificates: cULus, CCC
- Regulations: BG-GS-ET-15, EN ISO 13849-1, EN IEC 60947-5-1
General Data:
- Housing Material: Metal, zinc die-cast
- Housing Color: Silver
- Gross Weight: 340 g
General Data - Features:
- Indoor Installation: Yes
- Adjustable Switching Angle: Yes
- Mounting Stops: Yes
- Number of Auxiliary Contacts: 1
- Number of Safety Contacts: 2
Safety Considerations:
- Service Life: 20 years
- B10D Normally Closed (NC): 2,000,000 operations
- B10D Normally Open (NO): 1,000,000 operations
Mechanical Data:
- Mechanical Lifetime, Min.: 1,000,000 operations
Mechanical Data - Connection Technology:
- Connection Type: M12 connector
- Connection Cross Section, Min.: 0.5 mm²
- Connection Cross Section, Max.: 1 mm²
Mechanical Data - Dimensions:
- Sensor Length: 20 mm
- Sensor Width: 78 mm
- Sensor Height: 116 mm
Environmental Conditions:
- Protection Rating: IP65
- Ambient Temperature: -25 ... +65 °C
Environmental Conditions - Insulation Ratings:
- Rated Insulation Voltage Ui: 30 V
- Rated Impulse Withstand Voltage Uimp: 0.5 kV
Electrical Data:
- Thermal Continuous Current: 2.5 A
- Voltage, Operating Category AC-15: 230 VAC
- Current, Operating Category AC-15: 2 A
- Voltage, Operating Category DC-13: 24 VDC
- Current, Operating Category DC-13: 1 A
- Switching Element: Normally Open (NO), Normally Closed (NC)
- Switching Principle: Slow Action
- Maximum Switching Frequency: 1,200 /h
- Contact Material, Electrical: Silver-Nickel Alloy 10
Type: TESK-SU-12ST1
Questions & answers
What is the delivery time of Schmersal TESK-SU-12ST1 hinge safety switch 103005763?
The article Schmersal TESK-SU-12ST1 hinge safety switch 103005763 is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Schmersal 103005763 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Schmersal TESK-SU-12ST1 hinge safety switch 103005763 always at the best possible price. We can give you a discount of 2% on Schmersal TESK-SU-12ST1 hinge safety switch 103005763 if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 5 pieces of Schmersal TESK-SU-12ST1 hinge safety switch 103005763 we can offer you a price of 130,00 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
