Schmersal SLC 440-ER-1050-14-01 light curtain 14mm 101216626
|
4.541,59 EUR |
|||||||||||
|
( 5.404,49 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 1331057 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 101216626 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Schmersal 101216626:
Product Description in English:
The SLC440-ER-1050-14-01 safety light curtain offers state-of-the-art protection for personnel in industrial environments. With a protective field height of 1,050 mm and a detection capability of 14 mm, it provides maximum safety and precision. Its robust aluminum housing and IP67 protection ensure durability and reliability, even in demanding conditions. Integrated diagnostic and status displays, as well as Bluetooth functionality, make operation and monitoring straightforward.
Technical Data:
Product Type Designation:
- SLC440-ER-1050-14-01
Order Number:
- 101216626
EAN:
- 4030661409122
eCl@ss and ETIM Numbers:
- eCl@ss Version 12.0: 27-27-27-04
- eCl@ss Version 11.0: 27-27-27-04
- eCl@ss Version 9.0: 27-27-27-04
- ETIM Version 7.0: EC002549
- ETIM Version 6.0: EC002549
Approvals and Standards:
- Certifications: TÜV, cULus, ECOLAB
- Standards: EN IEC 61496-2, EN IEC 61496-1, EN ISO 13849-1, EN IEC 62061
Material and Weight:
- Housing Material: Aluminum
- Gross Weight: 1,830 g
Mechanical Properties:
- Protective Field Height: 1,050 mm
- Detection Capability: 14 mm
- Number of Beams: 104
- Range: 0.3 – 7 m
- Laser Diode Wavelength: 880 nm
Electrical Properties:
- Operating Voltage OSSD, HIGH Signal: 24 V
- Max. Electrical Power Consumption (Receiver): 10 W
- Max. Electrical Power Consumption (Transmitter): 5 W
- Safe Digital Outputs: p-switching, max. output current 0.25 A
Connection Technology:
- Connectors: M12, 8-pin (Receiver), M12, 4-pin (Transmitter)
- Maximum Cable Length: 100 m
Dimensions:
- Height Transmitter: 1,131 mm
- Height Receiver: 1,141 mm
- Length: 33 mm
- Width: 27.8 mm
Environmental Conditions:
- Protection Class: IP67
- Ambient Temperature: -25 ... +50 °C
- Storage and Transport Temperature: -25 ... +70 °C
Functions and Features:
- Restart Interlock: Yes
- Contactor Monitoring: Yes
- Beam Coding and Muting Function: Yes
- Diagnostic and Status Displays: Yes
- Bluetooth Capability: Yes
Delivery Scope:
- Transmitter and Receiver
- Mounting Set
Accessories:
- Recommended Safety Controller: SRB-E 301
Notes:
- Max. leakage current of 1 mA in case of fault (interruption of 0 V line).
Type: SLC440-ER-1050-14-01
Questions & answers
What is the delivery time of Schmersal SLC 440-ER-1050-14-01 light curtain 14mm 101216626?
The article Schmersal SLC 440-ER-1050-14-01 light curtain 14mm 101216626 is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Schmersal 101216626 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Schmersal SLC 440-ER-1050-14-01 light curtain 14mm 101216626 always at the best possible price. We can give you a discount of 2% on Schmersal SLC 440-ER-1050-14-01 light curtain 14mm 101216626 if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 2 pieces of Schmersal SLC 440-ER-1050-14-01 light curtain 14mm 101216626 we can offer you a price of 4.473,47 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
