Schmersal BNS 36-11 / 01Z-ST-L Security, Sensor
|
69,74 EUR |
|||||||||||
|
( 82,99 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 297494 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 101193236 | ||||||||||
| Weight: | 0 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Schmersal 101193236:
Product description in English:
The magnetic safety sensor BNS 36-11/01Z-ST-L provides reliable and precise monitoring of protective devices in industrial applications. Featuring a low coding level according to EN ISO 14119 and a robust housing made of fiberglass-reinforced thermoplastic, it is ideal for use in demanding environments.
The magnetic operating principle allows for tolerant installation, accommodating horizontal and vertical offsets between the sensor and actuator within the permissible range. Secure switching distances of 7 mm (ON) and 17 mm (OFF) ensure safe operation. The left-side door hinge and compact design facilitate integration into existing systems.
The sensor is equipped with two safety contacts (normally closed) and one auxiliary contact (normally open). The 6-pin M8 connector with snap-locking ensures a quick and secure connection. With an IP67 protection rating, the sensor is resistant to dust and moisture and is suitable for temperatures ranging from -25 °C to +70 °C.
Technical specifications:
Ordering information:
- Product designation: BNS 36-11/01Z-ST-L
- Article number: 101193236
- EAN: 4030661359922
- eCl@ss number: 27-27-44-01
- ETIM number: EC002544
Approvals and standards:
- Certifications: cULus
- Standards: BG-GS-ET-14, EN IEC 60947-5-3
Mechanical specifications:
- Operating principle: Magnetic
- Door hinge: Left
- Dimensions: Length 13 mm, Width 88 mm, Height 25 mm
- Protection class: IP67
- Lifespan: 25,000,000 switching cycles (B10D NC)
- Switching distances: Sao = 7 mm, Sar = 17 mm
- Connection type: M8 connector, 6-pin, snap-locking
Electrical specifications:
- Switching voltage: max. 30 VDC
- Switching current: max. 0.4 A
- Switching power: max. 10 W
- Switching elements: 1 normally open (NO), 2 normally closed (NC)
- Switching frequency: max. 5 Hz
Environmental conditions:
- Ambient temperature: -25 °C to +70 °C
- Vibration resistance: 10–55 Hz, amplitude 1 mm
- Shock resistance: 30 g / 11 ms
Special features:
- Magnetic operating principle tolerates horizontal and vertical offsets
- Note: Actuator is not included in the delivery
Accessories:
- Recommended actuator: BPS 36-2
- Recommended safety control units: SRB-E-301ST, SRB-E-201LC
Type: BNS 36-11/01z-ST-L
Questions & answers
What is the delivery time of Schmersal BNS 36-11 / 01Z-ST-L Security, Sensor?
The article Schmersal BNS 36-11 / 01Z-ST-L Security, Sensor is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Schmersal 101193236 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Schmersal BNS 36-11 / 01Z-ST-L Security, Sensor always at the best possible price. We can give you a discount of 2% on Schmersal BNS 36-11 / 01Z-ST-L Security, Sensor if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 6 pieces of Schmersal BNS 36-11 / 01Z-ST-L Security, Sensor we can offer you a price of 68,69 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
