Schmersal BNS 36-11Z-ST-R safety sensor 101193154
|
58,31 EUR |
|||||||||||
|
( 69,39 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 1237516 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 101193154 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Schmersal 101193154:
Product description in English:
The BNS 36-11Z-ST-R safety sensor provides a secure and efficient solution for machine and equipment protection. Its magnetic operating principle, combined with a low coding level as per EN ISO 14119, ensures reliable monitoring of protective devices. The compact design supports flush-mounted installation, and the sensor is made of robust, glass-fiber-reinforced thermoplastic for long-lasting durability.
With an IP67 protection rating and a maximum switching frequency of 5 Hz, the sensor is suitable for demanding environments. The M8 connector with a 4-pin locking mechanism ensures quick and secure installation. The sensor features one NO contact and one NC contact, specifically designed for right-hand door hinges.
Technical Specifications:
Ordering Information:
- Product Type: BNS 36-11Z-ST-R
- Article Number: 101193154
- EAN: 4030661359816
- eCl@ss Number: 27-27-44-01
- ETIM Number: EC002544
Approvals and Standards:
- Certificates: cULus
- Standards: BG-GS-ET-14, EN IEC 60947-5-3
General Data:
- Coding level as per EN ISO 14119: Low
- Operating principle: Magnetic
- Installation conditions: Flush-mounted
- Housing material: Glass-fiber-reinforced thermoplastic
- Gross weight: 29 g
Features:
- Number of NC contacts: 1
- Number of NO contacts: 1
- Number of safety contacts: 2
- Service life: 20 years
Mechanical Data:
- Actuator: Magnet
- Door hinge: Right-hand
- Movement direction: Frontal to active surface
- Switching distances: Sao: 7 mm, Sar: 17 mm
- Connection type: M8 connector, 4-pin, locking mechanism
- Dimensions: 13 mm (Length) x 88 mm (Width) x 25 mm (Height)
Environmental Conditions:
- Protection class: IP67
- Operating temperature: -25 to +70 °C
- Vibration resistance: 10 … 55 Hz, Amplitude 1 mm
- Shock resistance: 30 g / 11 ms
Electrical Data:
- Maximum switching voltage: 75 VDC
- Maximum switching current: 0.4 A
- Maximum switching power: 10 W
- Switching element: 1 NO contact, 1 NC contact
- Maximum switching frequency: 5 Hz
Scope of Delivery:
- Actuator not included.
Accessories:
- Recommended actuator: BPS 36-2
- Recommended safety relay: SRB-E-301ST, SRB-E-201LC
Note:
- Pin assignment for versions with an integrated connector is indicated in parentheses.
Type: BNS 36-11Z-ST-R
