Schmersal SRB 301HC/R-24V signal evaluation 101190594 content_copy

Order Data:

• Replaces Article Number: 101193476
• Product Type: SRB301HC/R-24V
• Article Number (Order Number): 101190594
• EAN (European Article Number): 4250116202317

• Version 12.0: 27-37-18-19
• Version 11.0: 27-37-18-19
• Version 9.0: 27-37-18-19

ETIM Number:

• Version 7.0: EC001449
• Version 6.0: EC001449

Note:

• Discontinued Product

Approvals - Regulations:

• Certificates:
- TÜV
- cULus
- TILVA


General Data:

• Regulations:
- EN IEC 62061
- EN ISO 13849-1
- EN IEC 60947-5-1
- EN IEC 60947-5-3
- EN IEC 60947-5-5
- EN IEC 61508
- EN IEC 60204-1
- EN IEC 60947-1


• Environmental Condition: EN 60068-2-78
• Housing Material: Plastic, glass-fiber reinforced thermoplastic, ventilated
• Gross Weight: 290 g

General Data - Features:

• Electronic Fuse: Yes
• Wire Break Detection: Yes
• Cross Short Detection: Yes
• Removable Terminals: Yes
• Start Input: Yes
• Feedback Loop: Yes
• Reset Edge Detection: Yes
• Ground Fault Detection: Yes
• Integrated Status Display: Yes
• Number of Auxiliary Contacts: 1
• Number of LEDs: 4
• Number of NC Contacts: 2
• Number of Safety Contacts: 3

Safety Consideration:

• Stop Category: 0
• Performance Level, Stop 0, up to: e
• Category, Stop 0: 4
• Diagnostic Coverage (DC) Level, Stop 0: ≥ 99 %
• PFH Value, Stop 0: 2,00 x 10⁻⁸ /h
• Safety Integrity Level (SIL), Stop 0, suitable for applications in: 3
• Service Life: 20 Years

Mechanical Data:

• Mechanical Lifetime, Minimum: 10,000,000 cycles
• Mounting: Quick fastening for DIN rail according to DIN EN 60715

Electrical Data:

• Frequency Range: 50 Hz / 60 Hz
• Operating Voltage: 24 VAC -15 % / +10 %, 24 VDC -10 % / +20 %
• Rated Operating Voltage: 24 VAC / 24 VDC
