Schmersal CSS 14-34F1-SDM-ST safety sensor 101189087
|
307,76 EUR |
|
|
( 366,23 EUR incl. VAT ) plus delivery charges |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 1320578 |
|---|---|
| Mfg Part No: | 101189087 |
| Weight: | 0 kg |
Product information for Schmersal 101189087:
Product Description in English:
The CSS 14-34F1-S-D-M-ST is a state-of-the-art safety sensor designed for applications with the highest safety requirements. Featuring a robust, glass-fiber-reinforced plastic housing and inductive operation, it delivers reliable performance in industrial environments. With its capability to daisy-chain up to 31 sensors and integrated diagnostic functions, it is versatile and efficient.
Technical Data:
Product Type Designation:
- CSS 14-34F1-S-D-M-ST
Order Number:
- 101189087
EAN:
- 4030661354873
eCl@ss and ETIM Numbers:
- eCl@ss Version 12.0: 27-27-46-01
- eCl@ss Version 11.0: 27-27-24-03
- eCl@ss Version 9.0: 27-27-24-03
- ETIM Version 7.0: EC001829
- ETIM Version 6.0: EC001829
Certificates:
- TÜV
- cULus
- UKCA
Material and Weight:
- Housing Material: Glass-fiber-reinforced thermoplastic
- Gross Weight: 141 g
Features:
- Operating Principle: Inductive
- Daisy-Chaining Device: Yes
- Maximum Daisy-Chaining: 31 Sensors
- Integrated Diagnostic Functions: Yes
- Maximum Reaction Time: 30 ms
- Integrated LEDs: 3
Safety Considerations:
- Performance Level: Up to e
- Category: 4
- PFH Value: 3.60 x 10⁻⁹ /h
- SIL: Up to 3
- Service Life: 20 Years
Mechanical Data:
- Installation Conditions: Non-flush
- Mechanical Lifespan: At least 1,000,000 Switching Cycles
- Active Area: Lateral
- Maximum Switching Frequency: 3 Hz
Mechanical Dimensions:
- Length: 35 mm
- Width: 27 mm
- Height: 108.2 mm
Connection Technology:
- Connection Type: M12 8-pin Plug
Environmental Conditions:
Electrical Data:
- Operating Voltage: 24 VDC
- Rated Operating Current: 600 mA
- Safe Digital Outputs: 2 (p-switching)
- Diagnostic Output: 1 (p-switching)
Recommended Accessories:
- Actuators: CST 34-S-1, CST 34-S-2, CST 34-S-3, CST 180-1, CST 180-2
- Safety Controllers: PROTECT PSC1, SRB-E-301ST, SRB-E-201LC
Notes:
For optimal safety, a dual-channel safety evaluation with p-switching sensors is recommended. The actuator is not included in the delivery.Type: CSS 14-34F1-S-D-M-ST
