Schmersal BNS 260-02Z-L safety sensor 101184385
|
59,41 EUR |
|||||||||||
|
( 70,70 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 1241248 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 101184385 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Schmersal 101184385:
Product description in English:
The BNS 260-02Z-L magnetic safety sensor is a reliable solution for securing protective devices, especially for left-hinged doors. Operating on the principle of magnetic detection, the sensor features a robust fiberglass-reinforced thermoplastic construction, ensuring long-lasting durability and high resistance to mechanical stresses.
With two normally closed (NC) contacts and a maximum switching power of 10 VA, the sensor guarantees top-level safety. Its quasi-flush mounting ensures seamless integration into various applications, while the flexible cable connection and a switching distance of up to 15 mm ensure easy installation and dependable operation.
Technical specifications:
Ordering information:
- Product type: BNS 260-02Z-L
- Article number: 101184385
- EAN: 4030661321851
- eCl@ss number: 27-27-44-01
- ETIM number: EC002544
Approvals and standards:
- Certifications: cULus
- Standards: BG-GS-ET-14, EN IEC 60947-5-3
General specifications:
- Coding level: Low
- Operating principle: Magnetic
- Material: Fiberglass-reinforced thermoplastic
- Gross weight: 55 g
Mechanical specifications:
- Door hinge: Left
- Movement direction: Frontal to the active surface
- Dimensions: Length 13 mm, Width 26 mm, Height 36 mm
- Switching distances: - Secured switching distance ON (Sao): 5 mm
- Connection type: Cable, Length 1 m, Conductor cross-section 0.25 mm²
- Secured switching distance OFF (Sar): 15 mm
Electrical specifications:
- Switching voltage: max. 75 VDC
- Switching current: max. 0.4 A
- Switching power: max. 10 VA
- Switching element: 2 normally closed (NC)
- Switching frequency: max. 5 Hz
Environmental conditions:
- Protection class: IP67
- Operating temperature: -25 °C to +70 °C
- Vibration resistance: 10–55 Hz, amplitude 1 mm
- Shock resistance: 30 g / 11 ms
Delivery:
- The actuator is not included in the scope of delivery.
Accessories:
- Recommended actuators: BPS 260
- Recommended safety control units: SRB-E-301ST, SRB-E-201LC
Notes:
- Representation of contact symbols when the protective device is closed.
- Contacts S11-S12 and S21-S22 must be integrated into the safety circuit.
Type: BNS 260-02Z-L
Questions & answers
What is the delivery time of Schmersal BNS 260-02Z-L safety sensor 101184385?
The article Schmersal BNS 260-02Z-L safety sensor 101184385 is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Schmersal 101184385 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Schmersal BNS 260-02Z-L safety sensor 101184385 always at the best possible price. We can give you a discount of 2% on Schmersal BNS 260-02Z-L safety sensor 101184385 if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 6 pieces of Schmersal BNS 260-02Z-L safety sensor 101184385 we can offer you a price of 58,52 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
