Schmersal 101168014 BN 20-11Z magnetic switch content_copy

The MELDELEUCHTE G24 -M20 is a compact signal light designed for status indication in industrial applications. Thanks to its robust construction and IP67 protection rating, this signal light is ideal for use in demanding environments. The integrated LEDs provide a reliable status indication in green or red, allowing operators to easily distinguish between different operating conditions.

The indicator light operates at a rated voltage of 24 VDC with a rated operating current of 20 mA. The sturdy housing allows a maximum torque load of 1.5 Nm during installation. The operating temperature range from -5 °C to +70 °C makes this signal light suitable for various environmental conditions.

Technical Data:

Product Type Designation:
MELDELEUCHTE G24 -M20

Article Number (Order Number):

101150877

EAN (European Article Number):

4030661287959

eCl@ss Numbers:
Version 12.0: 27-37-12-11
Version 11.0: 27-37-12-11
Version 9.0: 27-37-12-11

ETIM Numbers:

Version 7.0: EC000223
Version 6.0: EC000223

General Data:

Gross Weight:
15 g

Mechanical Data:

Maximum Torque:
1.5 Nm

Environmental Conditions:

Degree of Protection: IP67

Ambient Temperature:

-5 °C to +70 °C

Electrical Data:

Rated Operating Voltage:
24 VDC

Rated Operating Current:

20 mA

Status Indicator:

LED Color:
Green
Red
