Schmersal ELDE.NGB24 lighting element LED yellow screw 101165998
|
44,15 EUR |
|
|
( 52,54 EUR incl. VAT ) plus delivery charges |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 1331473 |
|---|---|
| Mfg Part No: | 101165998 |
| Weight: | 0 kg |
Product information for Schmersal 101165998:
The LED module ELDE.NGB24 is a compact and versatile solution for status indication in industrial applications. With an integrated yellow LED and a housing made of glass fiber-reinforced, self-extinguishing thermoplastic, it ensures high reliability and safety. The module is easily pluggable and suitable for any installation conditions. Supporting supply voltages of 24 VAC/DC, it offers flexibility in use. The IP20 protection rating for terminals and connections makes it ideal for use in protected environments.
Technical Data:
Product Designation:- ELDE.NGB24
Article Number:
- 101165998
EAN:
- 4250116200672
Certifications and Standards:
- cULus
- EN IEC 60947-5-1, EN IEC 60947-1
Design:
- LED module
Shape:
- With integrated LED
Materials:
- Housing: Plastic, glass fiber-reinforced thermoplastic, self-extinguishing
Gross Weight:
- 20 g
Features:
- Integrated Indicator: Yes
Mechanical Data:
- Mounting: Pluggable
- Mounting Flange Position: 3
Connection Technology:
- Connection Type: Screw terminals
- Connection Standards: EN 50005, EN 50013
- Connection Cross-section: - Rigid: 0.5 mm² to 2.5 mm²
- Length: 46 mm
- Width: 10 mm
- Depth: 60 mm
- Flexible: 0.5 mm² to 1.5 mm²
Dimensions:
Environmental Conditions:
- Terminal Protection Class: IP20
- Ambient Temperature: -25 °C to +80 °C
Insulation Ratings:
- Rated Insulation Voltage Ui: 440 V
Electrical Data:
- Operating Voltage: 24 VAC/DC
- Contact Designation: X1 - X2
Status Indicator:
- LED Color: Yellow
- Note: Supply Voltage UB: 24 VAC/DC
Type: ELDE.NGB24
Questions & answers
What is the delivery time of Schmersal ELDE.NGB24 lighting element LED yellow screw 101165998?
The article Schmersal ELDE.NGB24 lighting element LED yellow screw 101165998 is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Schmersal 101165998 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Schmersal ELDE.NGB24 lighting element LED yellow screw 101165998 always at the best possible price. We can give you a discount of 2% on Schmersal ELDE.NGB24 lighting element LED yellow screw 101165998 if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
