Schmersal AZ 16-12ZVRK-M20 Safety switch Separate actuator
|
49,14 EUR |
|||||||||||
|
( 58,48 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 336221 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 101157373 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Schmersal 101157373:
The AZ 16-12ZVRK-M20 safety switch is an electromechanical device used in machine and system control to ensure safety functions. Its robust design and high protection rating make it suitable for demanding environments.
Technical Data:
Product Designation:
- AZ 16-12ZVRK-M20
Article Number:
- 101157373
EAN:
- 4030661180038
eCl@ss Numbers:
- Version 12.0: 27-27-26-02
- Version 11.0: 27-27-26-02
- Version 9.0: 27-27-26-02
ETIM Numbers:
- Version 7.0: EC002592
- Version 6.0: EC002592
Approvals - Standards:
- Certificates: cULus, CCC
- Standards: EN ISO 13849-1, EN ISO 14119, EN IEC 60947-5-1
General Data:
- Coding Level (EN ISO 14119): Low
- Operating Principle: Electromechanical
- Housing Material: Plastic, glass-fiber-reinforced thermoplastic, self-extinguishing
- Gross Weight: 115 g
Features:
- Number of Approach Directions: 3
- Number of Auxiliary Contacts: 1
- Number of Safety Contacts: 2
- Number of Cable Entries: 3
Safety Consideration:
- Performance Level: Up to c
- Category: 1
- B10D NC Contacts: 2,000,000 cycles
- B10D NO Contacts: 1,000,000 cycles
- Service Life: 20 years
Mechanical Data:
- Mechanical Lifetime: Minimum 1,000,000 cycles
- Latching Force: 30 N
- Positive Opening Distance: 8 mm
- Positive Opening Force (per NC Contact): Minimum 10 N
- Operating Speed (max.): 2 m/s
- Mounting: Screws (2x M6)
Mechanical Data - Connection Technology:
- Cable Entry: 3 x M20 x 1.5
- Connection Type: Screw Terminals
- Conductor Cross-Section: 0.25 mm² to 2.5 mm²
Mechanical Data - Dimensions:
- Sensor Length: 30 mm
- Sensor Width: 52 mm
- Sensor Height: 90 mm
Environmental Conditions:
- Protection Class: IP67
- Operating Temperature: -30 °C to +80 °C
- Storage and Transport Temperature: -40 °C to +85 °C
Electrical Data:
- Thermal Continuous Current: 10 A
- Conditional Rated Short-Circuit Current: 1,000 A
- Switching Element: 1 NO, 2 NC
- Switching Principle: Slow-action, positive-opening contacts
Electrical Data - Safety Contacts:
- Voltage, Utilization Category AC-15: 230 VAC
- Current, Utilization Category AC-15: 4 A
- Voltage, Utilization Category DC-13: 24 VDC
- Current, Utilization Category DC-13: 4 A
Included in Delivery:
Type: AZ 16-12ZVRK-M20
Questions & answers
What is the delivery time of Schmersal AZ 16-12ZVRK-M20 Safety switch Separate actuator?
The article Schmersal AZ 16-12ZVRK-M20 Safety switch Separate actuator is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Schmersal 101157373 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Schmersal AZ 16-12ZVRK-M20 Safety switch Separate actuator always at the best possible price. We can give you a discount of 2% on Schmersal AZ 16-12ZVRK-M20 Safety switch Separate actuator if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 10 pieces of Schmersal AZ 16-12ZVRK-M20 Safety switch Separate actuator we can offer you a price of 48,40 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
