Schmersal AZ 415-11/11ZPK safety switch with separate actuator 101154000
|
185,88 EUR |
|||||||||||
|
( 221,20 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 1216022 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 101154000 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Schmersal 101154000:
The AZ 415-11/11ZPK-M20 safety switch is a high-quality electromechanical device designed for protective doors. Its robust aluminum housing and painted finish make it ideal for demanding environments. Featuring increased latching force and long service life, this switch is a reliable choice for industrial applications.
Technical Data:
Product Designation:
- AZ 415-11/11ZPK-M20
Article Number:
- 101154000
EAN:
- 4030661170701
eCl@ss Numbers:
- Version 12.0: 27-27-26-02
- Version 11.0: 27-27-26-02
- Version 9.0: 27-27-26-02
ETIM Numbers:
- Version 7.0: EC002592
- Version 6.0: EC002592
Approvals - Standards:
- Certificates: cULus, CCC
General Data:
- Housing Material: Aluminum
- Housing Coating: Painted
- Gross Weight: 495 g
Features:
- Increased Latching Force: Yes
- Number of Auxiliary Contacts: 3
- Number of Safety Contacts: 1
- Number of Protective Doors: 1
Safety Consideration:
- Standards: EN ISO 13849-1
- Service Life: 20 years
Safety Consideration - Safety Outputs:
- B10D NC Contacts: 2,000,000 cycles
- B10D NO Contacts: 1,000,000 cycles
- Note: B10D NO Contacts at 10% Ie and resistive load
Mechanical Data:
- Mechanical Service Life, Minimum: 1,000,000 cycles
- Latching Force, Minimum: 80 N
- Latching Force, Maximum: 400 N
- Positive Opening Travel: 3.8 mm
- Positive Opening Force, Minimum: 31 N
- Maximum Actuation Speed: 0.2 m/s
Mechanical Data - Connection Technology:
- Connection Type: Screw terminal M20 x 1.5
- Connection Cross Section: 2 x 0.75 mm² - 2 x 1.5 mm² (incl. ferrules)
Mechanical Data - Dimensions:
- Length: 46.5 mm
- Width: 84.6 mm
- Height: 103.6 mm
Environmental Conditions:
- Protection Class: IP67
- Operating Temperature: -25 to +70 °C
Environmental Conditions - Insulation Ratings:
- Rated Insulation Voltage Ui: 250 VAC
- Rated Impulse Withstand Voltage Uimp: 4 kV
Electrical Data:
Included in Delivery:
Type: AZ 415-11/11ZPK
Questions & answers
What is the delivery time of Schmersal AZ 415-11/11ZPK safety switch with separate actuator 101154000?
The article Schmersal AZ 415-11/11ZPK safety switch with separate actuator 101154000 is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Schmersal 101154000 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Schmersal AZ 415-11/11ZPK safety switch with separate actuator 101154000 always at the best possible price. We can give you a discount of 2% on Schmersal AZ 415-11/11ZPK safety switch with separate actuator 101154000 if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 5 pieces of Schmersal AZ 415-11/11ZPK safety switch with separate actuator 101154000 we can offer you a price of 183,09 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
