Schmersal AZM 170-02ZRI B1 24VAC/DC safety locking device 101140798
|
258,32 EUR |
|||||||||||
|
( 307,40 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 1216016 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 101140798 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Schmersal 101140798:
The cutting clamp technology allows for simple installation without ferrules. With a locking force of up to 1,300 N and robust construction, the AZM 170-02ZRI-B1 is optimized for industrial applications.
Technical Data:
Ordering Details:
- Product Type: AZM 170-02ZRI-B1 24VAC/DC
- Part Number: 101140798
- EAN: 4030661119861
- eCl@ss Number: 27-27-26-03
- ETIM Number: EC002593
General Data:
- Standards: BG-GS-ET-19, EN ISO 13849-1, EN ISO 14119, EN IEC 60947-5-1
- Coding: Individual Coding
- Housing Material: Plastic, glass-fiber-reinforced thermoplastic
- Actuator Material: Stainless Steel
- Gross Weight: 292 g
Mechanical Data:
- Mechanical Lifespan: Min. 1,000,000 switching cycles
- Actuation Radius: Min. 140 mm
- Locking Force FZh: 1,000 N (max. 1,300 N)
- Latching Force: 30 N
- Connection Type: Cutting Clamp Technology
- Dimensions (L x W x H): 30 mm x 90 mm x 84 mm
Electrical Data:
- Rated Control Supply Voltage: 24 VAC/DC
- Switching Element: 2 NC
- Switching Principle: Slow-action switching, forced-opening contacts
- Rated Insulation Voltage Ui: 250 VAC
- Electrical Power Consumption: Max. 12 W
Environmental Conditions:
- Protection Class: IP67
- Ambient Temperature: -25 °C to +60 °C
- Protection Class: II
Included in Delivery:
- Slot cover
- Actuator included (not reorderable)
Accessories:
- Triangular key M5 for emergency unlocking
Notes:
- Cutting clamp technology allows for easy installation without ferrules
- Manual unlocking with triangular key (available as an accessory)
Type: AZM 170-02ZRI-B1 24VAC/DC
