Schmersal safety switch, AZ 17-11ZK-ST
|
67,84 EUR |
|||||||||||
|
( 80,73 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 349576 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 101140772 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Schmersal 101140772:
The AZ 17-11ZK-ST safety switch is a compact electromechanical safety switch designed for a variety of safety applications. It is ideal for sliding, removable, or hinged safety guards and offers high reliability and a long service life. With IP67 protection and a robust glass-fiber-reinforced thermoplastic housing, it is resistant to challenging environmental conditions.
Technical Data:
Product Designation:
- AZ 17-11ZK-ST
Article Number:
- 101140772
EAN:
- 4030661119717
eCl@ss Numbers:
- Version 12.0: 27-27-26-02
- Version 11.0: 27-27-26-02
- Version 9.0: 27-27-26-02
ETIM Numbers:
- Version 7.0: EC002592
- Version 6.0: EC002592
Approvals - Standards:
- Certificates: IFA, cULus, CCC
- Standards: EN ISO 13849-1, EN ISO 14119, EN IEC 60947-5-1
General Data:
- Coding Level (EN ISO 14119): Low
- Operating Principle: Electromechanical
- Housing Material: Plastic, glass-fiber-reinforced thermoplastic, self-extinguishing
- Gross Weight: 85 g
Features:
- Number of Approach Directions: 2
- Number of Auxiliary Contacts: 1
- Number of Safety Contacts: 1
- Number of Cable Entries: 1
Safety Consideration:
- Performance Level: Up to c
- Category: 1
- B10D NC Contacts: 2,000,000 cycles
- B10D NO Contacts: 1,000,000 cycles
- Service Life: 20 years
Mechanical Data:
- Mechanical Lifetime: Minimum 1,000,000 cycles
- Latching Force: 5 N
- Positive Opening Distance: 11 mm
- Positive Opening Force (per NC Contact): Minimum 17 N
- Operating Speed (max.): 2 m/s
- Mounting: Screws (2x M4)
Mechanical Data - Connection Technology:
- Connection Type: M12 built-in connector, 4-pin, A-coding
Mechanical Data - Dimensions:
- Sensor Length: 30 mm
- Sensor Width: 30 mm
- Sensor Height: 78.5 mm
Environmental Conditions:
- Protection Class: IP67
- Operating Temperature: -30 °C to +80 °C
- Storage and Transport Temperature: -30 °C to +85 °C
Electrical Data:
- Thermal Continuous Current: 10 A
- Conditional Rated Short-Circuit Current: 1,000 A
- Switching Element: 1 NO, 1 NC
- Switching Principle: Slow-action, positive-opening contacts
Electrical Data - Safety Contacts:
- Voltage, Utilization Category AC-15: 230 VAC
- Current, Utilization Category AC-15: 4 A
- Voltage, Utilization Category DC-13: 24 VDC
- Current, Utilization Category DC-13: 4 A
Electrical Data - Auxiliary Contacts:
Other Data:
Included in Delivery:
Questions & answers
What is the delivery time of Schmersal safety switch, AZ 17-11ZK-ST?
The article Schmersal safety switch, AZ 17-11ZK-ST is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Schmersal 101140772 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Schmersal safety switch, AZ 17-11ZK-ST always at the best possible price. We can give you a discount of 2% on Schmersal safety switch, AZ 17-11ZK-ST if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 6 pieces of Schmersal safety switch, AZ 17-11ZK-ST we can offer you a price of 66,82 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
