Schmersal 101121963 Safety Switch, AZ 17-02ZI-B1
|
63,53 EUR |
|||||||||||
|
( 75,60 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 757714 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 101121963 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Schmersal 101121963:
Technical Data:
Product Designation:- AZ 17-02ZI B1
Article Number:
- 101121963
EAN:
- 4030661049717
Certifications and Standards:
- IFA, cULus
- EN ISO 13849-1, EN ISO 14119, EN IEC 60947-5-1
Coding Level:
- High according to EN ISO 14119
Operating Principle:
- Electromechanical
Materials:
- Housing: Plastic, glass fiber-reinforced thermoplastic, self-extinguishing
- Actuator: Stainless steel
Gross Weight:
- 95 g
Features:
- Number of Approach Directions: 2
- Number of Safety Contacts: 2
- Number of Cable Entries: 1
Safety Considerations:
- Performance Level: Up to PL c
- Category: 1 (up to 3 with dual-channel use and suitable logic unit)
- B10D NC: 2,000,000 cycles
- Service Life: 20 years
Mechanical Data:
- Mechanical Lifespan: Min. 1,000,000 cycles
- Latching Force: 5 N
- Positive Opening Distance: 11 mm
- Positive Opening Force per NC: Min. 17 N
- Total Positive Opening Force: Min. 34 N
- Actuation Speed: Max. 2 m/s
- Mounting: Screws (2x M5)
- Tightening Torque for Housing Cover: 0.7–1 Nm (Torx T10)
Connection Technology:
- Cable Entry: M 16 x 1.5
- Connection Type: Cutting clamp technology
- Conductor Cross-section: 0.75–1 mm², flexible
Dimensions:
- Length: 30 mm
- Width: 30 mm
- Height: 85 mm
Environmental Conditions:
- Protection Rating: IP67
- Ambient Temperature: -30 °C to +80 °C
- Storage and Transport Temperature: -30 °C to +85 °C
- Permissible Installation Altitude: Up to 2,000 m
Insulation Ratings:
- Rated Insulation Voltage: 250 VAC
- Rated Impulse Withstand Voltage: 4 kV
- Overvoltage Category: III
- Pollution Degree: 3
Electrical Data:
Electrical Data - Safety Contacts:
Scope of Delivery:
Notes:
Type: AZ 17-02ZI-B1
Questions & answers
What is the delivery time of Schmersal 101121963 Safety Switch, AZ 17-02ZI-B1?
The article Schmersal 101121963 Safety Switch, AZ 17-02ZI-B1 is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Schmersal 101121963 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Schmersal 101121963 Safety Switch, AZ 17-02ZI-B1 always at the best possible price. We can give you a discount of 2% on Schmersal 101121963 Safety Switch, AZ 17-02ZI-B1 if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 10 pieces of Schmersal 101121963 Safety Switch, AZ 17-02ZI-B1 we can offer you a price of 62,58 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
