Schmersal T3Z 068-22YR cable emergency switch 101087881
|
548,86 EUR |
|||||||||||
|
( 653,14 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 1312612 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 101087881 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Schmersal 101087881:
Product Description in English:
The T3Z 068-22YR is a robust and reliable rope pull emergency stop switch designed for demanding industrial environments. Featuring a painted cast iron housing and a maximum cable length of 50 meters, it is ideal for monitoring long areas. The device offers dual-sided operation and includes a pull ring release for easy use. With an IP65 protection rating and a wide operating temperature range, it is highly versatile.
Technical Data:
Product Type Designation:
- T3Z 068-22YR
Order Number:
- 101087881
EAN:
- 4030661057170
Approvals and Standards:
- Certificates: - TÜV
- Standards: - EN ISO 13850
- Housing Material: Painted Cast Iron
- Housing Cover Material: Painted Cast Iron
- Maximum Rope Length: 50 m
- Gross Weight: 4.540 g
- cULus
- CCC
- EN IEC 60947-5-1
- EN IEC 60947-5-5
General Data:
Features:
- Pull Ring Release: Yes
- Number of Auxiliary Contacts: 2
- Number of Safety Contacts: 2
Safety Considerations:
- Standards: EN ISO 13849-1
- Service Life: 20 years
- Safety Outputs (B10D NC): 100,000 operations
Mechanical Data:
- Actuator: Rope Pull Lever
- Mechanical Life, Minimum: 50,000 operations
- Forced Opening Angle: 32°
- Maximum Actuation Force: 50 N (30 N in cable direction)
- Actuation Direction: Right and Left (dual-sided operation)
- Minimum Forced Opening Force: 50 N
- Forced Opening Torque: 0.2 Nm
Connection Technology:
- Connection Type: Screw Terminal M20 x 1.5
- Connection Cross-Section: - Minimum: 0.75 mm²
- Protection Rating: IP65
- Ambient Temperature: -30 ... +90 °C
- Maximum: 1.5 mm² (including ferrules)
Environmental Conditions:
Insulation Characteristics:
- Rated Insulation Voltage Ui: 250 VAC
- Rated Impulse Withstand Voltage Uimp: 4 kV
Electrical Data:
- Thermal Continuous Current: 10 A
- Utilization Categories: - AC-15: 230 VAC / 2.5 A
- Switching Element: Normally Open (NO), Normally Closed (NC)
- Switching Principle: Slow-Acting
- Contact Material: Silver
- DC-13: 24 VDC / 6 A
Notes:
- Rope supports are required every 3 meters. For further details, refer to the accessories.
Type: T3Z 068-22YR
Questions & answers
What is the delivery time of Schmersal T3Z 068-22YR cable emergency switch 101087881?
The article Schmersal T3Z 068-22YR cable emergency switch 101087881 is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Schmersal 101087881 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Schmersal T3Z 068-22YR cable emergency switch 101087881 always at the best possible price. We can give you a discount of 2% on Schmersal T3Z 068-22YR cable emergency switch 101087881 if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 3 pieces of Schmersal T3Z 068-22YR cable emergency switch 101087881 we can offer you a price of 540,63 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
