Rittal 9677700 SV Component adaptor, 1000 A, 690 V, 3-pole, 185 mm, clamping attachment
|
72.985,74 EUR |
|
|
incl. 72.496,30 EUR copper surcharge ( 86.853,03 EUR incl. VAT ) ≈ £62,621.76 | ≈ $84,590.47 plus delivery charges: 148,00 € |
|
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |
| Lieske Part No.: | 410043 |
|---|---|
| Mfg Part No: | 9677700 |
| UPC/EAN: | 4028177707092 |
| Weight: | 15.3 kg |
Further Power distribution components from RittalFurther products in category Power distribution components
All products of Rittal
Product information for Rittal 9677700:
Material: Polyamide (PA 6.6)
Fire protection corresponding to UL 94-V0
Colour: RAL 7035
Note: For mounting on busbar systems with or without cover section
Suitable for the use of switchgear with front screw terminal
Cable outlet: Switch outlet or as outgoing cable from the switchgear
Packs of: 1 pc(s).
EAN: 4028177707092
Customs tariff number: 85369085
eCl@ss 5.1: 27370302
eCl@ss 7.0: 27370304
ETIM 6.0: EC001531
To fit busbars: with cross-section height: 10 mm
Number of poles: 3-pole
Installation type: Clamping attachment
For bar systems with centre-to-centre spacing: 185 mm
Dimensions: Width: 300 mm
Height: 652 mm
Rated operating voltage: 690 V, 3~
Rated current (max.): 1000 A
Cable outlet: Bottom
Suitable for brand: Manufacturer (type): ABB (Tmax T7 - 800 A/1000 A)
Manufacturer (type): Eaton (NZM4 - 800 A/1000 A)
Manufacturer (type): Schneider Electric (NS - 800 A/1000 A)
Manufacturer (type): Siemens (VL1250/3VL7 - 1000 A)
Type: SV 9677700
Fire protection corresponding to UL 94-V0
Colour: RAL 7035
Note: For mounting on busbar systems with or without cover section
Suitable for the use of switchgear with front screw terminal
Cable outlet: Switch outlet or as outgoing cable from the switchgear
Packs of: 1 pc(s).
EAN: 4028177707092
Customs tariff number: 85369085
eCl@ss 5.1: 27370302
eCl@ss 7.0: 27370304
ETIM 6.0: EC001531
To fit busbars: with cross-section height: 10 mm
Number of poles: 3-pole
Installation type: Clamping attachment
For bar systems with centre-to-centre spacing: 185 mm
Dimensions: Width: 300 mm
Height: 652 mm
Rated operating voltage: 690 V, 3~
Rated current (max.): 1000 A
Cable outlet: Bottom
Suitable for brand: Manufacturer (type): ABB (Tmax T7 - 800 A/1000 A)
Manufacturer (type): Eaton (NZM4 - 800 A/1000 A)
Manufacturer (type): Schneider Electric (NS - 800 A/1000 A)
Manufacturer (type): Siemens (VL1250/3VL7 - 1000 A)
Type: SV 9677700
Please note...
This article contains a copper surcharge of 72.496,30 EUR. This depends on daily copper prices and weight of included copper. You can inquire the copper price via phone under +49 7666 884990
Questions & answers
What is the delivery time of Rittal 9677700 SV Component adaptor, 1000 A, 690 V, 3-pole, 185 mm, clamping attachment?
The article Rittal 9677700 SV Component adaptor, 1000 A, 690 V, 3-pole, 185 mm, clamping attachment is currently not in stock but has been backordered.
According to our experience the article is ready for dispatch within 9 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 9677700 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Rittal 9677700 SV Component adaptor, 1000 A, 690 V, 3-pole, 185 mm, clamping attachment always at the best possible price. We can give you a discount of 2% on Rittal 9677700 SV Component adaptor, 1000 A, 690 V, 3-pole, 185 mm, clamping attachment if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
