Rittal 9209100 AX plastic Ex enclosure, 800x1000x300 mm, empty enclosure

Your rating:
Average rating
product review for Rittal 9209100 AX plastic Ex enclosure, 800x1000x300 mm, empty enclosure
( 4.5 / 5 ) 4 ratings
Rittal 9209100
This image may differ from the desired article.
Rittal 9209100Rittal 9209100Rittal 9209100Rittal 9209100Rittal 9209100Rittal 9209100Rittal 9209100Rittal 9209100
-10% 936,10 EUR 1.034,72 EUR
( 1.113,96 EUR incl. VAT )
≈ £783.52  |  ≈ $1,028.77
Delivery time from supplier's stock (ca.) 6 workdaysinfo_outline
In Stock: >5 pieces
1x Rittal 9209100 AX plastic Ex enclosure, 800x1000x300 mm, empty enclosure
Datasheet:file_download Download
Lieske Part No.:1989436
Mfg Part No: 9209100
UPC/EAN: 4028177952133
Weight:39.5 kg
Type:KE 9209100

Product information for Rittal 9209100:

The Rittal KE 9209100 is an Ex enclosure made of glass-fibre-reinforced, unsaturated polyester, designed for use in explosive atmospheres in accordance with Directive 2014/34/EU. It is approved for Zone 1 and 2 as well as Zone 21 and 22 and provides protection through increased safety (Ex e) and through the enclosure (Ex tb) in accordance with EN 60 079. The enclosure has dimensions of 800 mm (width) × 1,000 mm (height) × 300 mm (depth) and is available in the colour RAL 9011. It features a hinged door with a continuous silicone seal and a door opening angle of 130°. The door is equipped with a stainless steel hinge that can be reversed from left to right. The mounting plate made of galvanised steel sheet has dimensions of 705 mm × 925 mm and a material thickness of 3 mm. The scope of delivery includes the enclosure, the door, and the mounting plate.

Applications
This enclosure is designed for use in explosive atmospheres, particularly in Zone 1 and 2 (gaseous explosive atmospheres) and Zone 21 and 22 (dust explosive atmospheres) in accordance with EU Directive 2014/34/EU. The ambient temperature can range from -40 °C to +70 °C, although the actual operating temperature may be limited by installed components. The approvals include certificates IEC EX PTB 10.0011U and PTB 03 ATEX 1011U.

Functions and Equipment in Detail
The enclosure consists of a single-piece, impact-resistant plastic body made of glass-fibre-reinforced, unsaturated polyester, which is self-extinguishing according to UL 94 V-0. The surface resistances of the enclosure and door are below 10⁹ Ω, ensuring sufficient electrical insulation. The doors are fitted with a continuous silicone seal to ensure a tight seal. Double seals are integrated at the top and bottom edges of the door as rain protection strips. The mounting plate features keyhole slots for earthing and a printed QR code that links to product information and documentation.

Technical Explanation
The protection type Ex e (increased safety) ensures that no sparks or hot surfaces are generated that could ignite an explosive atmosphere. The protection type Ex tb (enclosure protection) ensures that the enclosure seals internal components from the environment, preventing any explosion inside from escaping outward. The protection rating IP 65 according to IEC 60 529 means dust-tight and protected against water jets, making it suitable for outdoor use. The NEMA protection ratings include Type 1, 3R, 3RX, 4, 4X, and 12, covering a wide range of environmental conditions. The IK code IK09 indicates high mechanical impact resistance.

Compatibility and Accessories
Various accessories are available for use with the enclosure, including wall mounting brackets for AX plastic in RAL 9011, door latches, universal angles, and plastic screws for internal installation. These components enable flexible mounting and adaptation to specific requirements.

Mounting and Installation
The enclosure is supplied as an empty housing with a hinged door and can be installed directly. The mounting plate provides numerous mounting holes for internal installation. The door can be mounted on either side (left or right), allowing for flexible installation. The integrated door stops at the top and bottom edges of the door facilitate mounting and secure closure.

Operational Advantages
The enclosure offers high mechanical strength and weather resistance. The materials are temperature-resistant between -40 °C and +70 °C and self-extinguishing. The integrated earthing via the keyhole slots on the mounting plate, as well as the QR codes for traceability and document access, enhance safety and maintainability. The protection ratings IP 65 and IK09 ensure reliable operation in demanding environments.

General
ModelEx enclosure
ApplicationsZone 1 and 2 or 21 and 22 according to 2014/34/EU, ambient temperature range: -40 °C...+70 °C, the specified temperatures may be limited by installed devices, protection type according to EN 60 079: device protection by increased safety (Ex e), device protection by enclosure (Ex tb)
MaterialHousing: glass-fibre-reinforced unsaturated polyester, surface resistance: < 10⁹ Ω, door: glass-fibre-reinforced unsaturated polyester, surface resistance: < 10⁹ Ω, continuously bonded silicone seal, mounting plate: sheet steel, zinc-coated
ColourRAL 9011
Scope of deliveryhousing, door, mounting plate
Width800 mm
Height1.000 mm
Depth300 mm
Mounting plate dimensions (W x H)705 mm x 925 mm
Mounting plate material thickness3 mm
LockNumber of locks: 3
Degree of protection IP according to IEC 60 529IP 65
NEMA degree of protectionType 1, Type 3R, Type 3RX, Type 4, Type 4X, Type 12
IK codeIK09
Operating temperature range-40 °C...70 °C
Operation temperatureThe specified temperatures may be limited by the installed devices
Certificate IEC EX PTB 10.0011UJa
Certificate PTB 03 ATEX 1011UJa


Please note...
This article has over-size and needs to be seperately taken care of. This is why we want to inform you, that the calculation of the delivery charges in the shopping cart will disregard this aspect. Though, there will be corresponding surcharges after you send us your order.
Product data sheet
Datasheet for Rittal 9209100, EAN: 4028177952133

Questions & answers

What is the delivery time of Rittal 9209100 AX plastic Ex enclosure, 800x1000x300 mm, empty enclosure?

The article Rittal 9209100 AX plastic Ex enclosure, 800x1000x300 mm, empty enclosure is currently in stock

According to our experience the article is ready for dispatch within 6 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 9209100 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Rittal 9209100 AX plastic Ex enclosure, 800x1000x300 mm, empty enclosure always at the best possible price. We can give you a discount of 2% on Rittal 9209100 AX plastic Ex enclosure, 800x1000x300 mm, empty enclosure if you choose payment in advance on ordering.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.




Fitting accessory for Rittal 9209100 AX plastic Ex enclosure, 800x1000x300 mm, empty enclosure

Rittal 1485500 AX wall mounting holder for AX plastic, RAL9011 Rittal LogoRittal 1485500 AX wall mounting holder for AX plastic, RAL9011 The Rittal AX 1485500 is a wall mounting bracket, specifically designed for mounting AX plastic enclosures on walls. The product serves as a mechanical fastening solution to securely and stably attach ...

Lieske Part No.: 705635
Mfg Part No: 1485500
Type: AX 1485500
16,45 EUR
Rittal 1485500 plus VAT
≈ £13.77  |  ≈ $18.08
Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline
Rittal 1485100 AX door latch for AX plastic Rittal LogoRittal 1485100 AX door latch for AX plastic The Rittal AX 1485100 is a door latch for AX plastic enclosures and plastic Ex enclosures. It is designed to secure the door of an enclosure in the open position, for example, to facilitate access to ...

Lieske Part No.: 1910561
Mfg Part No: 1485100
Type: AX 1485100
-12% 15,41 EUR 17,55 EUR
Rittal 1485100 plus VAT
≈ £12.90  |  ≈ $16.94
Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline
Rittal 1485200 Universal angle for AX plastic Rittal LogoRittal 1485200 Universal angle for AX plastic The Rittal AX 1485200 is a universal angle made of galvanised steel sheet, specifically developed for use in the internal assembly of AX plastic enclosures. It is used for mounting system chassis, ...

Lieske Part No.: 1910562
Mfg Part No: 1485200
Type: AX 1485200
7,13 EUR
Rittal 1485200 plus VAT
≈ £5.97  |  ≈ $7.84
Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline
Rittal 1485300 Plastic screw for internal assembly Rittal LogoRittal 1485300 Plastic screw for internal assembly The Rittal AX 1485300 is a plastic screw for the internal assembly of enclosures and housings from the AX system. It is used to secure accessory components to the mounting studs of the housing body.

Lieske Part No.: 1910563
Mfg Part No: 1485300
Type: AX 1485300
7,36 EUR
Rittal 1485300 plus VAT
≈ £6.16  |  ≈ $8.09
Delivery time from supplier's stock (ca.) 6 workdaysinfo_outline
