Rittal 7010210 Monitoring system CMC III leakage sensor

Your rating:
Average rating
product review for Rittal 7010210 Monitoring system CMC III leakage sensor
( 4.5 / 5 ) 2 ratings
Rittal 7010210
This image may differ from the desired article.
Rittal 7010210Rittal 7010210
261,74 EUR 270,55 EUR
( 311,47 EUR incl. VAT )
≈ £219.08  |  ≈ $287.65
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 5 workdaysinfo_outline
1x Rittal 7010210 Monitoring system CMC III leakage sensor
Datasheet:file_download Download
Lieske Part No.:611939
Mfg Part No: 7010210
UPC/EAN: 4069196000672
Weight:0.251 kg
Type:DK 7010210

Product information for Rittal 7010210:

The Rittal DK 7010210 is a leakage point sensor, specifically developed for monitoring enclosures, rooms, and containers in IT, industrial, and building technology environments. It is designed for the early detection of conductive liquids, such as water or coolant, that may reach the floor of an enclosure or technical unit. The functionality is based on conductivity monitoring between two contacts on the external sensor probe, which is mounted vertically to the floor. When a conductive liquid makes contact between these contacts, an alarm is triggered. The sensor can be connected to Rittal embedded devices such as the CMC III Processing Unit, PDU, LCP, or IoT Interface via a CAN-Bus interface. The connection is made directly through two RJ45 connectors, utilizing the integrated CAN-Bus. Automatic detection and integration into the bus sequence is achieved via Plug & Play, with the sensor being assigned a sequential number in the device management. An integrated multicolored LED serves as a status indicator for operation, warning, or alarm.

Applications

The sensor is designed for use in IT infrastructures, industrial plants, and building technology, where the risk of fluid leaks from cooling systems, water damage, or other sources exists. It is particularly suitable for use in server rooms, enclosures, containers, and other closed technical environments, where early notification of fluid contact is necessary to prevent damage to electronic components. Monitoring occurs directly at floor level, enabling even small leaks to be detected.

Functions and Equipment in Detail

The leakage point sensor features a compact plastic housing in RAL 9005 color, with a structured surface on the housing and a smooth front side. Dimensions are 110 mm width, 30 mm height, and 40 mm depth. The sensor is supplied with an external probe connected to the device via a cable with connector. Installation is carried out using the included mounting plate and fastening materials. Warning and alarm notifications are displayed via the software of Rittal embedded devices, enabling centralized monitoring and documentation.

Technology Explained Simply

The sensor’s technology is based on measuring electrical conductivity between two contacts on the probe. When a conductive liquid bridges the gap between these two points, an electrical resistance is measured and interpreted as an alarm. Power supply is provided via the CAN-Bus interface, eliminating the need for additional power sources. The CAN-Bus connection enables serial communication with higher-level devices, with data transmission occurring through two RJ45 connectors. The sensor’s protection rating is IP 20 according to EN 60 529, meaning it is protected against solid foreign objects (e.g., dust) but not against water. The sensor probe itself has an IP 20 rating, making it dust-tight and splash-proof, suitable for outdoor or humid environments.

Compatibility and Accessories

The sensor is compatible with Rittal embedded devices such as the CMC III Processing Unit, PDU, LCP, and IoT Interface. Connection is made via the CAN-Bus interface, and sensors can also be connected to each other in a bus configuration. Communication occurs through the integrated RJ45 connectors. Settings and configurations can be adjusted via the software of the higher-level devices. Additional sensors can be used, with the number and arrangement varying depending on application and environment.

Installation and Mounting

Installation is carried out using the included mounting plate and fastening materials. The external sensor probe is mounted vertically to the floor, with positioning chosen to cover the area where fluid leakage is most likely. Connection to the sensor is made via the cable with connector. Connection to the CAN-Bus system is achieved through the RJ45 connectors. Automatic detection and integration into the system is handled via Plug & Play, eliminating the need for manual configuration.

Operational Advantages

The sensor provides reliable and early detection of fluid leaks, helping to prevent damage to electronic components. Power supply via the CAN-Bus reduces the number of required cables and simplifies installation. Automatic detection and integration into the system reduces configuration time. Centralized display of warning and alarm notifications via the software of Rittal embedded devices enables efficient monitoring and documentation. The IP 20 protection rating of the sensor probe ensures robust use in humid or splash-prone environments.

Operating Environment

The sensor can operate within a temperature range of 0 °C to 45 °C, with sources indicating a range of 0 °C to 55 °C. Relative humidity is 5 % to 95 %, non-condensing. The operating environment must be dry and dust-free, as the IP 20 rating does not provide water tightness. However, the sensor probe is protected to IP 20, making it suitable for use in humid environments.

Scope of Delivery

The scope of delivery includes the leakage sensor, the external sensor probe with connection cable, the mounting plate, and the fastening materials.

General
ModelLeakage point sensor
ApplicationsMonitoring of cabinets in IT, industry and building technology. Monitoring of cabinets, rooms and containers in IT environment.
Function principleSettings can be made via the CMC III Processing Unit, the PDU, or via the IoT Interface. The leakage point sensor features an external probe mounted vertically to the floor. The sensor monitors the floor for conductive liquids (leakage) using two contacts.
MaterialPlastic
Surface protectionFront: smooth, Housing: textured
ColourRAL 9005
Scope of deliveryLeakage sensor, external sensor probe with cable, mounting plate, including fastening material
Connection to CAN busDirect
Interfaces2 x RJ45 CAN-bus
Width110 mm
Height30 mm
Depth40 mm
Operating temperature range0 °C...45 °C
Humidity (non-condensing)5...95 %


Product data sheet
Datasheet for Rittal 7010210, EAN: 4069196000672

Questions & answers

What is the delivery time of Rittal 7010210 Monitoring system CMC III leakage sensor?

The article Rittal 7010210 Monitoring system CMC III leakage sensor is currently not in stock and must be ordered on a per-order basis.

According to our experience the article is ready for dispatch within 5 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 7010210 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Rittal 7010210 Monitoring system CMC III leakage sensor always at the best possible price. We can give you a discount of 2% on Rittal 7010210 Monitoring system CMC III leakage sensor if you choose payment in advance on ordering.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
