Rittal 5501805 DK air baffle plate W x H: 600x2000 mm RAL9005
|
180,32 EUR 188,40 EUR |
|
|
( 214,58 EUR incl. VAT ) ≈ £150.93 | ≈ $198.17 plus delivery charges: 55,00 € |
|
| Made to order · Delivery time approx. 5 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 110197 |
| Mfg Part No: | 5501805 |
| UPC/EAN: | 4028177679177 |
| Weight: | 4.85 kg |
| Type: | DK 5501805 |
Product information for Rittal 5501805:
Applications: To separate the hot/cold zones within an enclosure with aisle containment or when using an LCP system.
Material: Sheet steel
Plastic to UL 94-V0
Surface finish: Spray-finished
Colour: RAL 9005
Supply includes: Assembly parts
Packs of: 1 pc(s).
EAN: 4028177679177
Customs tariff number: 73269098
eCl@ss 5.1: 27182501
eCl@ss 7.0: 27182590
ETIM 6.0: EC000331
Design: for TS IT 482.6 mm (48,3 cm ( 19 inch )) mounting angles
To fit: Width: = 600 mm
Height: = 2000 mm
Weight/pack: 5 kg
| General | |
| Applications | For separating cold/warm zones within a cabinet in case of gang enclosure or when using an LCP system. |
| Material | Steel sheet, blank panel: plastic, UL 94-HB, halogen-free, brush strip: plastic, UL 94-HB |
| Surface protection | Painted |
| Colour | RAL 9005 |
| Scope of delivery | 2 vertical panels, 2 horizontal panels, 4 brush strips, 4 cell-PU-foam pieces, including fastening material |
| Mounting note | The vertical panels with brush strips can be mounted on both the front and rear 19" profile rails for partitioning. Mounting of horizontal panels with brush strips is only possible on the front 19" profile rails. |
| Suitable for | Width: 600 mm, Height: 2.000 mm |
Questions & answers
What is the delivery time of Rittal 5501805 DK air baffle plate W x H: 600x2000 mm RAL9005?
The article Rittal 5501805 DK air baffle plate W x H: 600x2000 mm RAL9005 is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 5 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 5501805 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Rittal 5501805 DK air baffle plate W x H: 600x2000 mm RAL9005 always at the best possible price. We can give you a discount of 2% on Rittal 5501805 DK air baffle plate W x H: 600x2000 mm RAL9005 if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
