Rittal 3427040 SV Bus-mounting fuse base, DII-E27, 25 A, 500 V, 3-pole, round conductor connection 1,5-16 mm², adaptor screw, including cover plate
|
4.536,47 EUR |
|
|
incl. 4.399,39 EUR copper surcharge ( 5.398,40 EUR incl. VAT ) ≈ £3,892.29 | ≈ $5,257.77 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |
| Lieske Part No.: | 701509 |
|---|---|
| Mfg Part No: | 3427040 |
| UPC/EAN: | 4028177674974 |
| Weight: | 0.123 kg |
Product information for Rittal 3427040:
Contact hazard protection: Polyamide (PA 6.6)
Fire protection corresponding to UL 94-V0
Contact hazard protection: Polyamide (PA 6.6)
Colour: RAL 7035
Supply includes: Pre-configured element ready for connection including cover plate, contact hazard protection and exterior connection clamps
Note: For the use of fuse inserts to EN 60 269-3 (DIN VDE 0636-301)
Packs of: 5 pc(s).
EAN: 4028177674974
Customs tariff number: 85369085
eCl@ss 5.1: 27370302
eCl@ss 7.0: 27371402
ETIM 6.0: EC001644
Design: Easy Connect
To fit busbars: with cross-section height: 5 mm
with cross-section height: 10 mm
Number of poles: 3-pole
For bar systems with centre-to-centre spacing: 60 mm
Dimensions: Width: 56 mm
Height: 251 mm
Type of electrical connection: Box terminal
Rated operating voltage: 500 V, 3~
500 V (DC)
Connection for round conductor cross-sections: 1.5 mm² - 16 mm²
Note: Wire end ferrules should be used with fine wire conductors.
Rated current (max.): 25 A
Fuse inserts: D II-E 27 (adaptor screw)
Weight/pack: 2.12 kg
Type: SV 3427040
