Rittal 3304504 RTT Blue e cooling unit wall-mounted NEMA 4X, 1000 W, Com
|
3.346,50 EUR |
|
|
( 3.982,34 EUR incl. VAT ) ≈ £2,827.79 | ≈ $3,741.39 plus delivery charges |
|
| Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline | |
| In Stock: 3 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 929358 |
| Mfg Part No: | 3304504 |
| UPC/EAN: | 4028177384293 |
| Weight: | 58 kg |
| Type: | SK 3304504 |
Further Rack-Climatization from RittalFurther products in category Rack-Climatization
All products of Rittal
Product information for Rittal 3304504:
SK cooling device Blue e, wall-mounted, NEMA 4X, 1.1 kW, 230 V, 1~, 50/60 Hz, stainless steel, WHD: 405 x 1020 x 358 mm
Product description
Description: Energy-efficient Blue e wall-mounted cooling devices with standard integrated e- Comfort controller, RiNano coating on the condenser and electrical condensate evaporation. NEMA 4X protection rating.
Benefits: Can be networked with the IoT interface via Blue e IoT adapter
Material: Stainless steel 1.4404 (AISI 316L)
Protection class IP according to IEC 60 529: External circuit IP 34
Internal circuit IP 34
Protection class NEMA: with standard filter: NEMA 4X
Scope of delivery: Nano-coated condenser
Wired ready for connection (pluggable connection terminal strip )
Drilling template
Fastening material
Integrated electrical condensate evaporation
Variant: Wall mounting
Total cooling capacity according to DIN EN 14511: L 35 L 35 at 50 Hz: 1.1 kW
L 35 L 35 at 60 Hz: 1.25 kW
L 35 L 50 at 50 Hz: 0.91 kW
L 35 L 50 at 60 Hz: 0.9 kW
Air output (free-blowing): External circuit: 805 m³/h
Internal circuit: 600 m³/h
Rated operating voltage: 230 V, 1~, 50 Hz/60 Hz
Dimensions: Width: 405 mm
Height : 1020 mm
Depth: 358 mm
Temperature control: e-Comfort controller (factory setting +35 °C)
Temperature range: Operation (ambient): +10 °C...+55 °C
Setting range: +20 °C...+50 ° C
Refrigerant/cooling medium: Refrigerant: R134a
Quantity: 325 g
Global Warming Potential (GWP): 1430
CO2 equivalent (CO2e): 0.46 t
Rated power Pel: L 35 L 35 at 50 Hz: 0.64 kW
L 35 L 35 at 60 Hz: 0.68 kW
L 35 L 50 at 50 Hz: 0.71 kW
L 35 L 50 at 60 Hz: 0.81 kW
Rated current max.: At 50 Hz: 3.9 A
At 60 Hz: 4.3 A
Starting current (max.): At 50 Hz: 12 A
At 60 Hz: 14 A
Automatic circuit breaker/fuse: 10 A
Permissible operating pressure (p max.): 28 bar
Packaging unit: 1 piece
Weight/PU: 49 kg
EAN: 4028177384293
Customs tariff number : 84158200
ETIM 6.0: EC000855
ETIM 5.0: EC000855
eCl@ss 8.0/8.1: 27180704
eCl@ss 7.0/7.1: 27180704 eCl@
ss 6.0/6.1: 27180704
eCl@ss 5.1/5 .1.4: 27180704
Product description
Description: Energy-efficient Blue e wall-mounted cooling devices with standard integrated e- Comfort controller, RiNano coating on the condenser and electrical condensate evaporation. NEMA 4X protection rating.
Benefits: Can be networked with the IoT interface via Blue e IoT adapter
Material: Stainless steel 1.4404 (AISI 316L)
Protection class IP according to IEC 60 529: External circuit IP 34
Internal circuit IP 34
Protection class NEMA: with standard filter: NEMA 4X
Scope of delivery: Nano-coated condenser
Wired ready for connection (pluggable connection terminal strip )
Drilling template
Fastening material
Integrated electrical condensate evaporation
Variant: Wall mounting
Total cooling capacity according to DIN EN 14511: L 35 L 35 at 50 Hz: 1.1 kW
L 35 L 35 at 60 Hz: 1.25 kW
L 35 L 50 at 50 Hz: 0.91 kW
L 35 L 50 at 60 Hz: 0.9 kW
Air output (free-blowing): External circuit: 805 m³/h
Internal circuit: 600 m³/h
Rated operating voltage: 230 V, 1~, 50 Hz/60 Hz
Dimensions: Width: 405 mm
Height : 1020 mm
Depth: 358 mm
Temperature control: e-Comfort controller (factory setting +35 °C)
Temperature range: Operation (ambient): +10 °C...+55 °C
Setting range: +20 °C...+50 ° C
Refrigerant/cooling medium: Refrigerant: R134a
Quantity: 325 g
Global Warming Potential (GWP): 1430
CO2 equivalent (CO2e): 0.46 t
Rated power Pel: L 35 L 35 at 50 Hz: 0.64 kW
L 35 L 35 at 60 Hz: 0.68 kW
L 35 L 50 at 50 Hz: 0.71 kW
L 35 L 50 at 60 Hz: 0.81 kW
Rated current max.: At 50 Hz: 3.9 A
At 60 Hz: 4.3 A
Starting current (max.): At 50 Hz: 12 A
At 60 Hz: 14 A
Automatic circuit breaker/fuse: 10 A
Permissible operating pressure (p max.): 28 bar
Packaging unit: 1 piece
Weight/PU: 49 kg
EAN: 4028177384293
Customs tariff number : 84158200
ETIM 6.0: EC000855
ETIM 5.0: EC000855
eCl@ss 8.0/8.1: 27180704
eCl@ss 7.0/7.1: 27180704 eCl@
ss 6.0/6.1: 27180704
eCl@ss 5.1/5 .1.4: 27180704
Please note...
This article has over-weight and though needs to be transported by a forwarding agency. Please mind, that the calculation of the delivery charges in the shopping cart disregard this aspect.
Though, there will be corresponding surcharges after you send us your order.
