Rittal 3212230 Micro air/water heat exchanger wall-mounted, 300 W
|
-8% 537,05 EUR 581,64 EUR |
|
|
( 639,09 EUR incl. VAT ) ≈ £453.81 | ≈ $600.42 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline | |
| In Stock: >50 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 357280 |
| Mfg Part No: | 3212230 |
| UPC/EAN: | 4028177430938 |
| Weight: | 3.427 kg |
| Type: | SK 3212230 |
Further Rack-Climatization from RittalFurther products in category Rack-Climatization
All products of Rittal
Product information for Rittal 3212230:
Design: Water-carrying parts, copper/brass (Cu/CuZn)
Colour: RAL 7035
Protection category IP to IEC 60 529: IP 55
Supply includes: Fully wired ready for connection (plug-in terminal strip)
Drilling template
Sealing and assembly parts
Note: Integral non-return valve for version with e-Comfort controller
Packs of: 1 pc(s).
EAN: 4028177430938
Customs tariff number: 84158300
eCl@ss 5.1: 27180712
eCl@ss 7.0: 27180712
ETIM 6.0: EC002515
Total cooling output: L 35 W 10 at 200 l/h: 0.3 kW
Air throughput (unimpeded air flow): Internal circuit at 50 Hz: 280 m³/h
Internal circuit at 60 Hz: 310 m³/h
Rated operating voltage: 230 V, 1~, 50 Hz/60 Hz
Dimensions: Width: 150 mm
Height: 300 mm
Depth: 85 mm
Temperature range: Operation (environment): +1°C...+70°C
Water inlet: +1°C...+30°C
Refrigerant/cooling medium: Cooling medium: Water (see Internet for specifications)
Duty cycle: 100 %
Power consumption Pel: At 50 Hz: 23 W
At 60 Hz: 27 W
Rated current (max.): At 50 Hz: 0.11 A
At 60 Hz: 0.13 A
Pre-fuse: Miniature circuit-breaker/fuse: 2 A
Permissible operating pressure (p. max.): 1 bar - 10 bar
Water connections: ?" connector sleeve
Weight/pack: 3.2 kg
Colour: RAL 7035
Protection category IP to IEC 60 529: IP 55
Supply includes: Fully wired ready for connection (plug-in terminal strip)
Drilling template
Sealing and assembly parts
Note: Integral non-return valve for version with e-Comfort controller
Packs of: 1 pc(s).
EAN: 4028177430938
Customs tariff number: 84158300
eCl@ss 5.1: 27180712
eCl@ss 7.0: 27180712
ETIM 6.0: EC002515
Total cooling output: L 35 W 10 at 200 l/h: 0.3 kW
Air throughput (unimpeded air flow): Internal circuit at 50 Hz: 280 m³/h
Internal circuit at 60 Hz: 310 m³/h
Rated operating voltage: 230 V, 1~, 50 Hz/60 Hz
Dimensions: Width: 150 mm
Height: 300 mm
Depth: 85 mm
Temperature range: Operation (environment): +1°C...+70°C
Water inlet: +1°C...+30°C
Refrigerant/cooling medium: Cooling medium: Water (see Internet for specifications)
Duty cycle: 100 %
Power consumption Pel: At 50 Hz: 23 W
At 60 Hz: 27 W
Rated current (max.): At 50 Hz: 0.11 A
At 60 Hz: 0.13 A
Pre-fuse: Miniature circuit-breaker/fuse: 2 A
Permissible operating pressure (p. max.): 1 bar - 10 bar
Water connections: ?" connector sleeve
Weight/pack: 3.2 kg
