Rittal 3210100 SK Air/water heat exchanger, Roof-mounted, 4 kW, 230 V, 1~, 50/60 Hz, WHD: 597x417x475 mm, Basic controller
|
-6% 1.433,59 EUR 1.531,94 EUR |
|
|
( 1.705,97 EUR incl. VAT ) ≈ £1,231.45 | ≈ $1,642.89 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |
| Lieske Part No.: | 973498 |
|---|---|
| Mfg Part No: | 3210100 |
| UPC/EAN: | 4028177429932 |
| Weight: | 0.123 kg |
Further Rack-Climatization from RittalFurther products in category Rack-Climatization
All products of Rittal
Product information for Rittal 3210100:
Design: Water-carrying parts, copper/brass (Cu/CuZn)
Colour: RAL 7035
Protection category IP to IEC 60 529: IP 55
Note: IP 55 available on request
Supply includes: Fully wired ready for connection (plug-in terminal strip)
Drilling template
Sealing mat
Assembly parts
Packs of: 1 pc(s).
EAN: 4028177429932
Customs tariff number: 84158300
eCl@ss 5.1: 27180712
eCl@ss 7.0: 27180712
ETIM 6.0: EC002515
Total cooling output: L 35 W 10 at 400 l/h: 4 kW
Air throughput (unimpeded air flow): Internal circuit at 50 Hz: 815 m³/h
Internal circuit at 60 Hz: 925 m³/h
Rated operating voltage: 230 V, 1~, 50 Hz/60 Hz
Dimensions: Width: 597 mm
Height: 417 mm
Depth: 475 mm
Temperature control: Basic controller (factory setting +35°C)
Temperature range: Operation (environment): +1°C...+70°C
Setting range: +20°C...+55°C
Water inlet: +1°C...+30°C
Refrigerant/cooling medium: Cooling medium: Water (see Internet for specifications)
Type of electrical connection: Plug-in terminal strip
Duty cycle: 100 %
Power consumption Pel: At 50 Hz: 100 W
At 60 Hz: 120 W
Rated current (max.): At 50 Hz: 0.44 A
At 60 Hz: 0.5 A
Pre-fuse: Miniature circuit-breaker/fuse: 4 A
Permissible operating pressure (p. max.): 1 bar - 10 bar
Water connections: ½" connector sleeve
G ?" external thread
Weight/pack: 25.5 kg
Type: SK 3210100
Colour: RAL 7035
Protection category IP to IEC 60 529: IP 55
Note: IP 55 available on request
Supply includes: Fully wired ready for connection (plug-in terminal strip)
Drilling template
Sealing mat
Assembly parts
Packs of: 1 pc(s).
EAN: 4028177429932
Customs tariff number: 84158300
eCl@ss 5.1: 27180712
eCl@ss 7.0: 27180712
ETIM 6.0: EC002515
Total cooling output: L 35 W 10 at 400 l/h: 4 kW
Air throughput (unimpeded air flow): Internal circuit at 50 Hz: 815 m³/h
Internal circuit at 60 Hz: 925 m³/h
Rated operating voltage: 230 V, 1~, 50 Hz/60 Hz
Dimensions: Width: 597 mm
Height: 417 mm
Depth: 475 mm
Temperature control: Basic controller (factory setting +35°C)
Temperature range: Operation (environment): +1°C...+70°C
Setting range: +20°C...+55°C
Water inlet: +1°C...+30°C
Refrigerant/cooling medium: Cooling medium: Water (see Internet for specifications)
Type of electrical connection: Plug-in terminal strip
Duty cycle: 100 %
Power consumption Pel: At 50 Hz: 100 W
At 60 Hz: 120 W
Rated current (max.): At 50 Hz: 0.44 A
At 60 Hz: 0.5 A
Pre-fuse: Miniature circuit-breaker/fuse: 4 A
Permissible operating pressure (p. max.): 1 bar - 10 bar
Water connections: ½" connector sleeve
G ?" external thread
Weight/pack: 25.5 kg
Type: SK 3210100
