Rittal 2736540 FT System window, for TS, SE, 60 section, WHD: 500x670x77 mm, for W: 600 mm
|
-7% 235,92 EUR 252,43 EUR |
|||||||||||
|
( 280,74 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 357721 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 2736540 | ||||||||||
| UPC/EAN: | 4028177476448 | ||||||||||
| Weight: | 6.5 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Rittal 2736540:
Benefits: Base frame: Easily screw-fastened to the door thanks to modified dimensions (tubular door frame may be used as a drilling template).
Base frame: Readily height-adjustable.
Base frame: Stabilises the door cut-out.
Base frame: Conceals the cut edge.
Base frame: The rain canopy prevents dirt from landing on the seal, protects the glass from being lifted out, prevents the ingress of dirt and moisture when opening the window.
Base frame: Frame section height 30 mm or 60 mm
Viewing window: Made from single-pane safety glass: High level of resistance to solvents and scratches, anti-static, reduced risk of injury if broken.
Viewing window: Hinge with 180° opening angle, easily inserted.
Material: Extruded aluminium section with die-cast zinc corner pieces and single-pane safety glass.
Surface finish: Base frame: Powder-coated on the outside in RAL 7035
Hinge and lock section: Natural-anodised
Protection category IP to IEC 60 529: IP 54
Assembly instruction: Standard double-bit lock insert may be exchanged for lock inserts 27 mm, type A, and/or for lock system Ergoform-S (except H = 270 mm).
Packs of: 1 pc(s).
EAN: 4028177476448
Customs tariff number: 76101000
eCl@ss 5.1: 27182301
eCl@ss 7.0: 27182301
ETIM 6.0: EC002527
Design: 60 section
To fit: Enclosure type: TS 8
Enclosure type: SE 8
Width: = 600 mm
Dimensions: Width: 500 mm
Height: 670 mm
Depth: 77 mm
Viewing area: Width: 363 mm
Height: 598 mm
Build depth for components (max.): 63 mm
Weight/pack: 6.85 kg
Type: FT 2736.540
