Rittal 2735590 FT System window, for TS, SE, 30 section, WHD: 700x570x47 mm, for W: 800 mm
|
-7% 228,49 EUR 244,49 EUR |
|||||||||||
|
( 271,90 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 504061 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 2735590 | ||||||||||
| UPC/EAN: | 4028177476363 | ||||||||||
| Weight: | 6.22 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Rittal 2735590:
Benefits: Base frame: Easily screw-fastened to the door thanks to modified dimensions (tubular door frame may be used as a drilling template).
Base frame: Readily height-adjustable.
Base frame: Stabilises the door cut-out.
Base frame: Conceals the cut edge.
Base frame: The rain canopy prevents dirt from landing on the seal, protects the glass from being lifted out, prevents the ingress of dirt and moisture when opening the window.
Base frame: Frame section height 30 mm or 60 mm
Viewing window: Made from single-pane safety glass: High level of resistance to solvents and scratches, anti-static, reduced risk of injury if broken.
Viewing window: Hinge with 180° opening angle, easily inserted.
Material: Extruded aluminium section with die-cast zinc corner pieces and single-pane safety glass.
Surface finish: Base frame: Powder-coated on the outside in RAL 7035
Hinge and lock section: Natural-anodised
Protection category IP to IEC 60 529: IP 54
Assembly instruction: Standard double-bit lock insert may be exchanged for lock inserts 27 mm, type A, and/or for lock system Ergoform-S (except H = 270 mm).
Packs of: 1 pc(s).
EAN: 4028177476363
Customs tariff number: 76101000
eCl@ss 5.1: 27182301
eCl@ss 7.0: 27182301
ETIM 6.0: EC002527
Design: 30 section
To fit: Enclosure type: TS 8
Enclosure type: SE 8
Width: = 800 mm
Dimensions: Width: 700 mm
Height: 570 mm
Depth: 47 mm
Viewing area: Width: 563 mm
Height: 498 mm
Build depth for components (max.): 33 mm
Weight/pack: 6.55 kg
Type: FT 2735.590
Questions & answers
What is the delivery time of Rittal 2735590 FT System window, for TS, SE, 30 section, WHD: 700x570x47 mm, for W: 800 mm?
The article Rittal 2735590 FT System window, for TS, SE, 30 section, WHD: 700x570x47 mm, for W: 800 mm is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 2735590 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Rittal 2735590 FT System window, for TS, SE, 30 section, WHD: 700x570x47 mm, for W: 800 mm always at the best possible price. We can give you a discount of 2% on Rittal 2735590 FT System window, for TS, SE, 30 section, WHD: 700x570x47 mm, for W: 800 mm if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 5 pieces of Rittal 2735590 FT System window, for TS, SE, 30 section, WHD: 700x570x47 mm, for W: 800 mm we can offer you a price of 225,06 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
