RED 2410-50-0007 Blind button 1-pole FR AP IP54 250V 10A IK05
|
53,84 EUR 56,10 EUR |
|||||||||||
|
( 64,07 EUR incl. VAT ) ≈ £46.25 | ≈ $61.70 plus delivery charges: 53,00 € |
|||||||||||
| Delivery time from supplier's stock (ca.) 2 workdaysinfo_outline | |||||||||||
| In Stock: >5 pieces | |||||||||||
| Lieske Part No.: | 2022321 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 2410-50-0007 | ||||||||||
| UPC/EAN: | 4046725358541 | ||||||||||
| Weight: | 0.123 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Further Waterproof wall switch from REDFurther products in category Waterproof wall switch
All products of RED
Product information for RED 2410-50-0007:
SPLASH® blind switch rocker switch, 1-pole with N terminal and reversing lock. The SPLASH® series impresses with its large interior for easy wiring. The quick connections with plug-in terminals up to 2.5 mm2 and the patented, asymmetrical cable entry seals allow quick and easy installation. Through-wiring of the devices with 2.5 mm2 wires is also possible. In addition, the SPLASH® product range from RED has special earthing connections that enable switching in a group. The VDE-certified products are tested for impact resistance IK05. The SPLASH® series is available in gray. It is possible to use a labeling field for switches and sockets, which is available as an option. It can be opened and protected against the ingress of water and moisture by a plastic cover. Illuminated switch variants are available. In an almost optimal way, SPLASH® is manufactured with protection against dust and water ingress to guarantee protection class IP54. Wet areas, harsh conditions, dust, smoke, ...: the SPLASH® product range from RED is excellently suited to these requirements. 5 year guarantee.
Technical data
. Nominal voltage: 250 V
. Nominal current: 10 A
. Protection class: IP54
. Impact resistance: IK05
. Color: light gray RAL 7035
. Composition: base element with complete housing
. Installation type: surface-mounted
. Fastening type: screw fastening
. Material: thermoplastic, untreated
. Switching current for fluorescent lamps: 10 AX
. Connection type: plug-in terminal
Type: 2410-50-0007
Technical data
. Nominal voltage: 250 V
. Nominal current: 10 A
. Protection class: IP54
. Impact resistance: IK05
. Color: light gray RAL 7035
. Composition: base element with complete housing
. Installation type: surface-mounted
. Fastening type: screw fastening
. Material: thermoplastic, untreated
. Switching current for fluorescent lamps: 10 AX
. Connection type: plug-in terminal
Type: 2410-50-0007
