RCS Audio-Systems TRT-400 A ›VARES-LOOP‹ ring bus module, with volume control 60W, IP 21C, including cover
|
489,25 EUR |
|||||||||||
|
( 582,21 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time from supplier's stock (ca.) 7 workdaysinfo_outline | |||||||||||
| Lieske Part No.: | 1927725 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | TRT-400 A | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for RCS Audio-Systems TRT-400 A:
The module supports two usage scenarios: It allows for individual volume adjustment of a general background music feed, or it can be used to inject a separate 100V audio program to the connected loudspeaker. In both cases, the volume control is automatically bypassed during emergency announcements, ensuring full-volume playback.
Powered via the Ringbus and controlled by the TRC-800 A, the TRT-400 A also monitors its connections for faults such as short circuits, open circuits, and ground faults.
Technical Specifications (English):
Model:
- TRT-400 A
Power Supply (via TRC-800 A):
- 19 – 30 V DC (Nominal 30 V DC)
- Idle current: 100 µA
- Max. Power Consumption: 20 mW
Control Signal:
- 20 kHz / 7.5 Vrms
Switching Times:
- Fade-in: 0.3 s
- Fade-out: 1.0 s
Wiring:
- 2-wire system, max. 2.5 mm²
- Max. loop length: 1,000 m
- Max. cable diameter: 13 mm
T-Branch (End-of-Line):
- Max. 50 W
- EoL resistor: 47 kOhm, 0.25 W or higher
Speaker Type:
- Not specified (designed for 100V systems with volume control)
LOOP Fault Detection:
- Short circuit
- Wire-to-wire
- Open circuit
- Ground fault
Mounting:
- Surface-mounted near speaker
Connections:
- Loop Input: L+, L−, GND (0.8–2.5 mm²)
- Loop Output: L+, L−, GND (0.8–2.5 mm²)
- Speaker: L+, L−, GND (0.8–2.5 mm²)
- LED: L+, L− (0.8–2.5 mm²)
Housing / Protection:
- ABS with transparent cover
- IP21C
Dimensions (W x H x D):
- 110 x 130 x 55 mm
Weight:
- 160 g
Certification:
- EN 54-17:2005
- Certificate: 0560-CPR-142190002
Special Features:
- 60 W volume control
- Two modes: Volume adjustment or dedicated 100V feed
- Auto-bypass during alarms
- Integrated line monitoring and fault detection
